HARWIN M80 Series Straight Through Hole PCB Socket 16-Contact, 2 Row, 2 mm Pitch, 12A, 120V M80-8501645
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M80-8501645 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Beryllium Copper Alloy, Brass |
| Series | M80 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Constructed for through-hole mounting with a straight orientation.
- Housing is made of durable nylon material ensuring robust insulation.
- Contacts are female with beryllium copper alloy and brass base for high reliability.
- Gold plating ensures superior connectivity and corrosion resistance.
- Operates efficiently between -55°C to 125°C temperature range.
- Designed for board-to-board connection applications with 120V rating.
- Part of the M80 series, known for high-reliability connectors with four-finger beryllium copper contacts.
- Suitable for applications exposed to vibration, shock, and harsh environmental conditions.
Product Description
The HARWIN M80-8501645 is a high-quality straight through hole PCB socket designed with 16 female contacts arranged in 2 rows, featuring a precise 2 mm pitch and rated for 12A current and 120V voltage. This connector is engineered for through-hole mounting with a straight orientation, offering excellent mechanical stability and ease of assembly in PCB applications.
Its housing is made from durable nylon material providing excellent insulation, while the contacts are crafted from a beryllium copper alloy and brass, plated with gold to ensure outstanding electrical conductivity and resistance to corrosion. Designed to operate reliably from -55°C to 125°C, this PCB socket is well suited for harsh industrial and electronic manufacturing environments where high levels of vibration, shock, and mechanical stress are present.
Part of the M80 series, this socket incorporates Harwin's high reliability four-finger contact design providing excellent retention force and long life over multiple mating cycles. The 2-row, 16-contact configuration is ideal for board-to-board interfacing where secure connections and signal integrity are critical.
The M80-8501645 socket is widely used in commercial, industrial, and laboratory applications that demand robust, high-quality connectors with reliable performance over time. Its compatibility with industry-standard mating components makes it an excellent choice for new designs or refurbishment projects.
Constructed for through-hole mounting with a straight orientation. Nylon housing material for robust insulation and mechanical strength. High-quality female contacts made from beryllium copper alloy and brass. Gold plating on contacts for optimal electrical performance.
Wide operating temperature range of -55°C to 125°C. Designed for 12A current and 120V voltage board-to-board systems. Durable and reliable in harsh environments with shock and vibration. Part of the proven M80 connector series with four-finger contact technology.
Manufactured in the United Kingdom maintaining high quality standards. Ideal for use in industrial, manufacturing, and electronic component assembly. Explore a broad range of PCB Sockets and connectors at EnvMart to find the ideal components for your electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HARWIN M80-8501645 PCB socket has a maximum current rating of 12A.
This model is rated for a voltage of 120V.
It operates efficiently within a temperature range of -55°C to 125°C.
The M80-8501645 features 16 female contacts arranged in 2 rows.
The contacts are made from a beryllium copper alloy and brass, with gold plating for enhanced conductivity and corrosion resistance.
This socket is designed for through-hole mounting with a straight orientation.
The pitch of the contacts is 2 mm.
The housing is constructed from durable nylon material, providing excellent insulation.
It is designed for board-to-board connection applications, particularly in environments exposed to vibration and shock.
Yes, it incorporates a four-finger contact design that provides excellent retention force and long life over multiple mating cycles.
This product is manufactured in the United Kingdom, adhering to high quality standards.
The termination type for this model is solder.
