TRACOPOWER Medical 10W Ultra-Wide Input Range DC/DC Converter Through Hole DIP THM 10-4823WI
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THM 10WI DC/DC Converter, 15V dc/ 333 m |
| Brand | TRACOPOWER |
| Efficiency | 0.88% |
| Length | 31.8mm |
| Model | THM 10-4823WI |
| Depth | 10.2mm |
| Gross Weight | 14g |
| Width | 20.3mm |
| Mount Type | Through Hole |
| Series | THM 10WI |
| Maximum Operating Temperature | 90°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 3850000h |
| Number of outputs | 2 |
| Ripple and Noise | 40mV Pk-Pk |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 75V dc |
| Minimum Input Voltage | 18V |
| Number of Pins | 7 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 333mA |
| Isolation Voltage | 5kV dc |
| Input Ratio | 4:1 |
| Output Voltage 2 | -15V dc |
| Input Ratio4 | 1 |
| The Traco THM 10-4823WI is a medical 10 Watt DC/DC converter with ultra-wide 4 | 1 input voltage range. It provides a very low leakage current of less than 2 μA. It constitute a reliable solution not only for medical equipment but also for demanding ranges of application such as transportation, control & measurement or IGBT drive |
Key Features
- Operates with an input voltage range from 18 V to 75 V DC.
- Provides dual output voltages of ±15 V DC with output current up to 333 mA.
- Designed with a through-hole DIP package for easy PCB mounting.
- Maintains high efficiency at 88% ensuring low power loss during operation.
- Withstands operating temperatures from -40°C up to 90°C for robust performance.
- Features 5 kV DC isolation voltage for enhanced safety in medical and industrial environments.
- Extremely low leakage current under 2 μA, ideal for sensitive medical equipment.
- Reliability demonstrated by MTBF of 3,850,000 hours for prolonged service life.
Product Description
TRACOPOWER THM 10-4823WI is a medically certified 10 Watt DC/DC Converter featuring a robust ultra-wide 4:1 input voltage range from 18 V to 75 V DC. This DIP through-hole package device provides dual ±15 V DC output voltages at up to 333 mA output current, delivering reliable power conversion ideal for precision medical, transportation, control, measurement, and IGBT driver applications.
Operating efficiently at 88%, the THM 10-4823WI ensures minimal losses and thermal stress with a maximum operating temperature of 90°C and a minimum of -40°C, enabling performance stability across harsh industrial environments. Its high isolation voltage of 5 kV DC and ultra-low leakage current of less than 2 μA elevate safety levels suited for stringent medical standards.
The converter offers a mean time between failure (MTBF) rating of 3,850,000 hours, underscoring its reliability for critical continuous use scenarios. Compact in size with dimensions of 31.8 mm by 20.3 mm by 10.2 mm, and a lightweight 14 grams, it fits seamlessly into compact PCB layouts.
TRACOPOWER ensures compliance with IEC/EN/ES 60601-1 3rd edition certification and adheres to IPC-A-610 Level 3 assembly quality regulations as well as ISO 14971 risk management protocols. This makes the THM 10-4823WI suitable for medical and industrial applications requiring rigorous safety and quality standards.
Wide 4:1 input voltage range from 18 V to 75 V DC. Dual output voltages of ±15 V DC with 333 mA max output current each. Through Hole DIP-24 plastic package ensuring secure PCB mount. High efficiency operation at 88% reduces heat dissipation.
Operation guaranteed between -40°C and +90°C ambient temperatures. 5 kV DC isolation voltage for robust safety compliance. Extremely low leakage current under 2 microamps for sensitive equipment. MTBF of 3.85 million hours ensures long-term reliability.
Certified to IEC/EN/ES 60601-1 standard for medical safety. Compact and lightweight design with 14 g weight.
Ideal industrial uses include medical electronics, transportation control systems, measurement instrumentation, and IGBT driver circuits. EnvMart offers this TRACOPOWER model as a trusted solution for demanding DC power supply needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates with an input voltage range from 18 V to 75 V DC.
This model provides dual output voltages of ±15 V DC with a maximum output current of 333 mA for each output.
It maintains a high efficiency of 88%, ensuring low power loss during operation.
The converter features a high isolation voltage of 5 kV DC, enhancing safety for medical and industrial applications.
It can operate in ambient temperatures ranging from -40°C to +90°C.
This unit has dimensions of 31.8 mm by 20.3 mm by 10.2 mm and weighs 14 grams, making it compact for PCB layouts.
It is designed with a through-hole DIP package for easy PCB mounting.
The MTBF rating is 3,850,000 hours, indicating reliability for long-term use.
The output ripple and noise is specified at 40 mV peak-to-peak.
It is ideal for use in medical electronics, transportation control systems, measurement instrumentation, and IGBT driver circuits.
It is certified to IEC/EN/ES 60601-1 for medical safety and adheres to IPC-A-610 Level 3 assembly quality regulations.
It features an extremely low leakage current of less than 2 μA, making it suitable for sensitive medical equipment.
