Samtec Right Angle Through Hole PCB Socket 60-Contact, 2 Row, 0.55 mm Pitch, 220V, 21.8A Current QSH-030-01-L-D-K-TR

Free Delivery in India | Lowest Global Shipping Charges

Samtec Right Angle Through Hole PCB Socket 60-Contact, 2 Row, 0.55 mm Pitch, 220V, 21.8A Current QSH-030-01-L-D-K-TR

Name: Samtec Right Angle Through Hole PCB Socket 60-Contact, 2 Row, 0.55 mm Pitch, 220V, 21.8A Current QSH-030-01-L-D-K-TR
Brand: Samtec
SKU: 163258
Price: 13.07 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	220V
Brand	Samtec
Orientation	Right Angle
Current	21.8A
Model	QSH-030-01-L-D-K-TR
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	QSH-RA
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Right Angle Ground Plane
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	0.55mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	60
Connector System	Board-to-Board

Key Features

The socket utilizes phosphor bronze contacts with gold plating for enhanced conductivity and corrosion resistance.
Housing material is high-performance Liquid Crystal Polymer ensuring durability and stability.
Designed for through hole mounting with board-to-board connector system.
Operating temperature ranges from -55°C to 125°C for reliable performance in various environments.
Complies with RoHS standards for environmental and safety regulations.
Series QSH-RA offers high-speed ground plane with differential pair and right angle orientation.

Product Description

Samtec QSH-030-01-L-D-K-TR is a high-quality right angle through hole PCB socket designed for reliable electronic connections with 60 contacts arranged in 2 rows. This socket features a fine pitch of 0.55 mm making it suitable for compact PCB designs requiring efficient board-to-board connectivity.

The contacts are made from phosphor bronze and plated with gold to ensure excellent electrical conductivity and resistance against corrosion, which enhances longevity and performance in demanding electronic applications. The housing is constructed from Liquid Crystal Polymer, a material known for its mechanical strength and thermal stability, thereby ensuring resiliency in harsh conditions.

Designed for through hole mount technology and right angle orientation, this PCB socket supports a current rating of 21.8A and a voltage rating of 220V, suitable for various industrial, communication, and electronic equipment assemblies.

The operating temperature range extends from -55°C to 125°C allowing the socket to function reliably in diverse environmental conditions. It also complies with RoHS directives ensuring that it meets environmental safety standards.

This product is part of the Samtec QSH-RA series, renowned for high-speed ground plane capabilities and differential pair support, making it ideal for sophisticated PCB designs needing robust and stable connections.

The socket uses gold plated phosphor bronze contacts for enhanced conductivity. Liquid Crystal Polymer housing provides durability and thermal resistance. Supports a maximum operating temperature of 125°C and minimum of -55°C.

High-speed ground plane and differential pair capable QSH-RA series product. Right angle orientation for board-to-board mounting applications.

This Samtec PCB socket is widely used in electronics manufacturing, industrial controls, communication devices, and other applications requiring reliable and compact PCB interconnections.

Explore the Electronics Components category at EnvMart for a broad range of sockets and connectors from Samtec and other leading brands.

Explore more products in our PCB Sockets category.
