Texas Instruments MOSFET Gate Driver 2 Outputs 1.5 A 16-Pin PDIP 40V UC3706N
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 4.57mm |
| Length | 19.3mm |
| Model | UC3706N |
| Width | 6.35mm |
| Mount Type | Through Hole |
| Series | UC3706 |
| Output Current | 1.5A |
| Maximum Operating Temperature | 70°C |
| Package Type | PDIP |
| Minimum Operating Temperature | 0°C |
| Number of outputs | 2 |
| Rise Time | 110ns |
| Pin Count | 16 |
| Minimum Supply Voltage | 40V |
| Number of Drivers | 2 |
| Fall Time | 80ns |
| Driver Type | MOSFET |
| Infineon 2EDN7434FXTMA1 MOSFET Gate Driver, 4 A 8-Pin 20V, DSOBrand | Infineon |
Key Features
- The driver features fast rise and fall times of 110ns and 80ns respectively.
- It operates from 0°C to 70°C, supporting industrial temperature ranges.
- Designed for through hole mounting with a compact form factor of 19.3mm length by 6.35mm width.
- Supports 2 driver outputs suitable for MOSFET and IGBT power devices.
- This gate driver is ideal for power management IC applications in electronics and electrical industries.
Product Description
Texas Instruments UC3706N MOSFET Gate Driver is a robust power management integrated circuit designed to deliver high current drive outputs compatible with MOSFET and IGBT devices. The IC features two outputs capable of sourcing 1.5 A current, allowing efficient switching performance in various industrial and electronics applications.
This device comes in a 16-pin PDIP through-hole package with dimensions of approximately 19.3mm length, 6.35mm width, and 4.57mm height, suitable for easy PCB integration. It supports a supply voltage range up to 40V with fast switching speeds characterized by rise and fall times of 110ns and 80ns, respectively. The operational temperature range spans from 0°C to 70°C, making it suitable for controlled industrial environments.
The UC3706N series provides reliable gate drive solutions especially for power management IC requirements in semiconductors and electronics systems, ensuring optimal MOSFET and IGBT performance. Its through-hole mount enhances durability in manufacturing processes and prototyping stages.
The driver features fast rise and fall times of 110ns and 80ns respectively. It operates from 0°C to 70°C, supporting industrial temperature ranges. Designed for through hole mounting with a compact form factor of 19.3mm length by 6.35mm width.
Supports 2 driver outputs suitable for MOSFET and IGBT power devices. This gate driver is ideal for power management IC applications in electronics and electrical industries. Applications include industrial power management, laboratory instrumentation, electronics manufacturing, and embedded system designs requiring precise MOSFET gate control.
Explore similar Texas Instruments power management IC products and gate drivers within the EnvMart catalog for comprehensive semiconductor solutions.
