Samtec SSQ Series Straight Through Hole PCB Socket 24-Contact 2 Row 2.54 mm Pitch Through Hole SSQ-112-01-F-D

Samtec SSQ-112-01-F-D PCB Socket 24-Contact 2 Row 2.54 mm Pitch Through Hole is a new, high-quality connector suitable for board-to-board interfacing in a variety of electronic and industrial applications.

This socket features a through hole mounting style with a straight orientation, ensuring robust mechanical and electrical connections on printed circuit boards. The housing is crafted from liquid crystal polymer which offers excellent durability and resistance to heat and chemicals.

The socket includes 24 female contacts arranged in 2 rows with a 2.54 mm pitch, utilizing phosphor bronze contact material for its excellent conductivity and strength. The contacts are plated with gold, enhancing corrosion resistance and reliability over repeated mating cycles.

Electrical specifications include a current rating of 6.3A per pin (with 2 pins powered), voltage rating of up to 655V, and a normal contact force of 125 grams (4.4N). It supports a maximum of 100 mating cycles with 10 microinch (0.25 μm) gold plating to maintain low contact resistance.

This connector is designed to operate within a wide temperature range from -55°C to 125°C, making it suitable for industrial, electronic, telecommunications, manufacturing, and laboratory applications. The SSQ series is known for its precision engineering and reliability in PCB socket solutions.

Features such as through hole termination and board-to-board connectivity make this product ideal for custom PCB assemblies demanding high current and voltage capabilities with long-term operational stability.

Samtec's innovative Tiger Buy™ contact system ensures performance excellence and lead-free solder compatibility, facilitating environmentally friendly manufacturing processes. Features 24 female contacts arranged in 2 rows for reliable connectivity.

2.54 mm pitch with square tail termination ensures compatibility with standard PCBs. Current rating of 6.3A per pin supports robust electrical performance. Constructed with liquid crystal polymer housing and phosphor bronze contacts plated with gold for durability.

Operates reliably from -55°C to 125°C temperature range. Designed with a straight orientation and through hole mount for secure PCB installation. Voltage rating up to 655V suitable for demanding electronic applications. Supports 100 mating cycles with low contact resistance.

Lead free solderable and compliant with environmental standards. Part of the SSQ series known for precision and reliability. Explore more electronic components and PCB socket solutions in our Electronics Components category on EnvMart for industrial, manufacturing, and design use cases.
