STMicroelectronics Low Power Quad Operational Amplifier 1.3 MHz Gain Bandwidth, 30V SOIC 14-Pin LM2902YDT

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Low Power Quad Operational Amplifier 1.3 MHz Gain Bandwidth, 30V SOIC 14-Pin LM2902YDT

Name: STMicroelectronics Low Power Quad Operational Amplifier 1.3 MHz Gain Bandwidth, 30V SOIC 14-Pin LM2902YDT
Brand: STMicroelectronics
SKU: 219337
Price: 0.23 USD
Availability: InStock



Category Operational Amplifier Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	1.65mm
Length	8.75mm
Model	LM2902YDT
Width	4mm
Mount Type	Surface
Series	LM2902
Output Current	70mA
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Number Of Channels	4
Standards/Approvals	RoHS
Pin Count	14
Automotive Standard	AEC-Q100
Maximum Supply Voltage	30V
Minimum Supply Voltage	5V
GBP - Gain Bandwidth Product	1.3MHz
Input Bias Current	300 nA
Vos - Input Offset Voltage	9 mV
Slew Rate	0.4V/μs
Input Offset Current	40 nA
Max input offset voltage	9mV (LM2902), 4mV (LM2902A)

Key Features

Suitable for applications requiring a maximum supply voltage of 30V.
Features a low input bias current of 300 nA and input offset voltage maximum of 9 mV.
Operates efficiently within a temperature range from -40°C to 125°C.
Provides an output current capability up to 70 mA.
Compact dimensions with a length of 8.75 mm, width of 4 mm, and height of 1.65 mm.
Includes slew rate of 0.4 V/μs ensuring responsive performance.
Compliant with RoHS standards and automotive qualified per AEC-Q100.
Designed for surface mounting in SOIC package format with 14 pins and four independent channels.

Product Description

STMicroelectronics LM2902YDT is a low power quad operational amplifier featuring four independent amplifiers with internal frequency compensation. It offers a gain bandwidth product of 1.3 MHz and operates reliably at supply voltages ranging from 5V to 30V. The device comes in a compact 14-pin SOIC surface mount package with dimensions suitable for modern electronic circuit designs.

This operational amplifier exhibits a slew rate of 0.4 V/μs and a maximum input offset voltage of 9 mV, suitable for precision signal processing applications. The low input bias current of 300 nA and input offset current of 40 nA contribute to its energy-efficient operation.

Designed to operate in a wide ambient temperature range from -40°C to 125°C, the LM2902YDT is robust for automotive and industrial environments, backed by AEC-Q100 automotive qualification. The maximum output current capability of 70 mA supports diverse load driving requirements.

The compact SOIC package ensures easy surface mounting on PCBs in manufacturing for aerospace, automotive, industrial controls, and general electronics applications. Its RoHS compliance confirms adherence to environmental and safety standards.

These amplifiers are highly versatile and ideal for signal conditioning, filtering, and instrumentation in industrial and electronic component manufacturing sectors. The package contains a single unit of LM2902YDT operational amplifier in 14-pin SOIC format ready for automated assembly lines.

Low power, quad independent operational amplifiers with internal frequency compensation. Gain bandwidth product of 1.3 MHz for high-frequency applications. Slew rate of 0.4 V/μs enabling fast response times. Wide operating voltage range from 5 V to 30 V.

High maximum operating temperature of 125°C suited for automotive and industrial use. Compact dimensions with 14-pin SOIC package for automated PCB assembly. Compliance with RoHS and automotive standard AEC-Q100 ensures reliability and safety.
