Samtec ERF8 Series Vertical Through Hole PCB Socket, 26-Contact, 2 Row, 0.8 mm Pitch, 2.2A Current, 318V Voltage

Samtec ERF8 ERF8-013-05.0-L-DV-L-K-TR Vertical Through Hole PCB Socket is engineered to provide reliable and high speed board-to-board connectivity with 26 contacts arranged in 2 rows and a precise 0.8 mm pitch. Operating with a current capacity of 2.2 A per contact and supporting voltages up to 318 V, this socket is ideal for demanding electronic applications.

The socket’s housing is constructed from black liquid crystal polymer, which ensures excellent thermal stability across a wide operating temperature range from -55°C to 125°C. Contacts are crafted from beryllium copper alloy with gold plating, delivering superior electrical performance and corrosion resistance.

Its through-hole mount type with vertical orientation and an 18 mm stacking height provides a sturdy mechanical fit suited for various PCB assembly configurations. The row pitch of 4.5 mm and rugged design enable effective signal integrity, supporting single-ended and differential pair routing with PAM4 56 Gbps data performance.

Applications of this ERF8 series PCB socket span across industrial electronics, communication equipment, instrumentation, and high-speed data devices where robust and precise board-to-board connections are crucial.

This vertical PCB socket supports a current rating of 2.2 A per contact. The socket uses a high-quality beryllium copper alloy contact material with gold plating for reliable performance. It features a black liquid crystal polymer housing for durability at high temperatures.

Designed for through-hole mounting with a vertical orientation and 18 mm stacking height. The operating temperature ranges from -55°C to 125°C, suitable for demanding industrial applications. The connector system supports board-to-board connections with a 4.5 mm row pitch.

This ERF8 series socket delivers 56 Gbps PAM4 data rate performance for high-speed signal routing. Voltage rating is 318 V ensuring stable operation in power-sensitive devices. Explore more technical products in the Electronics Components PCB Socket category at EnvMart to find solutions tailored to your application needs.
