Samtec ESQ Series Vertical Through Hole PCB Socket 4-Contact 1 Row 2.54 mm Pitch Solder ESQ-104-12-G-S

Samtec ESQ-104-12-G-S is a high-quality vertical through hole PCB socket from the ESQ series, designed for board-to-board connection applications. Featuring 4 contacts arranged in a single row with a 2.54 mm pitch, it provides reliable and stable solder termination.

The housing is constructed from black glass filled polyester, combining strength and electrical insulation. The contacts are composed of phosphor bronze material with gold plating, ensuring excellent electrical conductivity and resistance to corrosion over long operational periods.

This socket is rated for a current of 5.7 A per pin and can handle voltages up to 515 V, supporting demanding industrial and electronic environments. Its operational temperature range from -55°C to 125°C makes it suitable for applications exposed to extreme temperature variations.

With a through hole mount and vertical orientation, the ESQ-104-12-G-S ensures secure and mechanically robust board interconnections. It also includes normal force contacts providing 125 grams (4.4 N) insertion force and is designed to withstand up to 100 mating cycles with a gold plating thickness of 10μ" (0.25μm), ensuring longevity and reliable performance.

This product complies with RoHS standards, demonstrating Samtec's commitment to environmentally responsible manufacturing. Ideal for industrial electronics, manufacturing equipment, and embedded system applications requiring durable and certified PCB socket connectors.

The housing is made from black glass filled polyester ensuring durability. Contact material is phosphor bronze with gold plating for superior conductivity and corrosion resistance. Rated for 5.7 A current and 515 V voltage, suitable for various electronics applications.

Operates reliably between -55°C to 125°C, suitable for harsh environments. Designed with standard and low insertion force contacts for PC/104 applications. Through hole mount type with vertical orientation facilitates robust mechanical stability.

Supports up to 100 mating cycles with 10μ" (0.25μm) gold plating thickness. Compliance with RoHS standards ensures environmental safety. Explore more high-quality PCB Sockets and connectors on EnvMart for your electronics manufacturing and prototyping needs.
