Samtec ESQ Series Vertical Through Hole PCB Socket, 40-Contact, 2 Row, 2.54 mm Pitch, 6.9A Current, Gold over Tin ESQ12039GD

Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin India
Voltage 550V
Brand Samtec
Orientation Vertical
Current 6.9A
Model ESQ12039GD
Mount Type Through Hole
Contact Material Bronze
Series ESQ
Termination Type Solder
Maximum Operating Temperature 125°C
Minimum Operating Temperature -55°C
Number of Rows 2
Pitch 2.54mm
Standards/Approvals RoHS
Contact Plating Gold over Tin
Number of Contacts 40
Connector System Board-to-Board

Key Features

  • Gold-plated contacts provide high electrical conductivity.
  • Current rating of 6.9A per contact supports demanding electrical requirements.
  • Vertical orientation enables straightforward and space-saving board stacking.
  • Constructed with corrosion-resistant phosphor bronze pins for durability in humid environments.
  • Insulated glass-filled polyester body prevents electric shock during installation.
  • Operating temperature range from -55°C to 125°C ensures suitability for varied conditions.
  • Low average insertion force of 0.9N reduces operator fatigue during assembly.
  • Meets RoHS standards for environmental compliance.

Product Description

The Samtec ESQ Series Vertical Through Hole PCB Socket ESQ12039GD features 40 gold-plated contacts arranged in 2 rows with a 2.54 mm pitch, designed for robust board-to-board connections in electronic assemblies.

Its vertical orientation facilitates easy stacking of circuit boards, making it ideal for applications requiring high-density configurations such as data centers, security systems, military and defense equipment, as well as medical and pharmaceutical devices.

The contacts are made of corrosion-resistant phosphor bronze with gold over tin plating, ensuring excellent electrical conductivity and durability, even in humid environments. The socket's contact system, known as Tiger Buy contacts, provides extended insertion depth and superior retention force, reducing maintenance needs.

The body is constructed from insulated glass-filled polyester, offering electrical insulation and protection against electrical shock during assembly. This socket supports a current rating of 6.9A per contact and voltage up to 550V, suitable for demanding electrical setups.

The product operates reliably over a wide temperature range from -55°C to 125°C, allowing use in various industrial and commercial environments. Its low insertion force of 0.9N eases installation and reduces fatigue for operators handling the component.

Gold-plated contacts for high electrical conductivity and corrosion resistance. High current rating of 6.9A per pin supports robust electrical connections. Vertical through hole mount for easy and secure PCB attachment. Durable phosphor bronze contacts with gold over tin plating.

Insulated glass-filled polyester body for electrical safety. Wide temperature operating range from -55°C to 125°C. Low insertion force enhances ease of assembly and operator comfort. Complies with RoHS environmental standards for sustainability.

This Samtec PCB socket is well-suited for industrial, telecommunications, security, military, medical, and pharmaceutical manufacturing applications. Its reliable construction and performance meet rigorous demands in these sectors.

Explore more Samtec PCB Sockets and connectors on EnvMart for efficient and reliable electronic component assembly solutions.
