Samtec ESQ Series Vertical Through Hole PCB Socket 4-Contact 1 Row 2.54 mm Pitch 515V 5.7A ESQ-104-14-G-S

Free Delivery in India | Lowest Global Shipping Charges

Samtec ESQ Series Vertical Through Hole PCB Socket 4-Contact 1 Row 2.54 mm Pitch 515V 5.7A ESQ-104-14-G-S

Name: Samtec ESQ Series Vertical Through Hole PCB Socket 4-Contact 1 Row 2.54 mm Pitch 515V 5.7A ESQ-104-14-G-S
Brand: Samtec
SKU: 162222
Price: 2.36 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	515V
Brand	Samtec
Orientation	Vertical
Current	5.7A
Model	ESQ-104-14-G-S
Mount Type	Through Hole
Housing Material	Black Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	ESQ
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	1
Max Cycles	100 with 10μ" (0.25μm) Au
Pitch	2.54mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	4
Connector System	Board-to-Board

Key Features

Designed for board-to-board connection with a vertical orientation.
Made of black glass filled polyester housing for durability.
Phosphor bronze contacts plated with gold ensure reliable conductivity.
Supports a current rating of 5.7 amps at 515 volts.
Rated for operation between -55°C and 125°C.
Mount type is through hole for stable PCB integration.
Standard force contacts offer 125 grams (4.4N) normal force.
Durability rated for 100 mating cycles with 0.25μm gold plating thickness.

Product Description

The Samtec ESQ-104-14-G-S is a vertical through hole PCB socket designed for reliable board-to-board connections. It features 4 contacts arranged in a single row with a spacing pitch of 2.54 mm, making it suitable for PC/104 applications and other electronic assemblies requiring standard pitch connectors.

This socket uses solder termination and a black glass filled polyester housing, which provides excellent mechanical strength and thermal stability. Its phosphor bronze contacts plated with gold offer superior electrical performance and corrosion resistance.

Rated for 515 volts and capable of handling up to 5.7 amps of current per contact, this connector supports demanding electrical conditions. It operates reliably across a wide temperature range from -55°C to 125°C, making it suitable for industrial, laboratory, and commercial electronics environments.

The contact normal force is specified at 125 grams (4.4 Newtons), delivering an optimal balance between contact retention and low insertion force. This socket is designed to endure up to 100 mating cycles without significant performance degradation thanks to its 0.25 micron gold plating thickness.

This component is ideal for use in electronics manufacturing, testing, and repair applications that require durable and precise vertical board-to-board sockets. Its through hole mount ensures a secure connection to the PCB, enhancing mechanical stability and signal integrity.

Designed for board-to-board connection with a vertical orientation. Durable black glass filled polyester housing. Phosphor bronze contacts with gold plating for optimal conductivity. High current rating of 5.7 amperes and voltage rating of 515 volts.

Wide operating temperature range from -55°C to 125°C. Standard contact force of 125 grams ensures reliable connections. Durability supporting 100 mating cycles with quality gold plating. Explore more electronics components and connectors with EnvMart's extensive catalog of industrial and commercial PCB Sockets from trusted brands like Samtec.
