Samtec 20-Way Shrouded Male PCB Header for Surface Mount, 2 Row, 1.27mm Pitch ESHF-110-01-L-D-SM-LC

Samtec ESHF-110-01-L-D-SM-LC is a high-quality 20-way shrouded male PCB header designed for surface mounting on printed circuit boards. It features two rows of contacts with a standard 1.27mm pitch, suitable for a variety of electronic applications.

The connector housing is composed of black liquid crystal polymer, ensuring excellent insulation and resistance under changing environmental conditions. The phosphor bronze contacts, plated with tin and gold, offer optimal conductivity and corrosion resistance.

This PCB header supports a broad operating temperature range from -55°C to 125°C, making it ideal for industrial, commercial, and telecommunications electronics environments. It employs an IDC termination type facilitating efficient and secure wire terminations, while the shrouded design enhances connection reliability by preventing misalignment and damage.

Its surface mount type with a straight orientation allows seamless integration into PCBs with tight tolerances. The SMT leads provide a coplanarity of up to 0.10mm ensuring reliable solder joints and assembly quality.

This PCB header features 20 contacts arranged in 2 rows for reliable circuit connections. The shrouded design protects the connector and enhances polarization. Constructed with phosphor bronze contacts plated with tin and gold for durability.

Mount type is surface mount, with a straight orientation for easy PCB assembly. Insulator housing is made of black liquid crystal polymer ensuring high thermal and mechanical stability. Operates within a wide temperature range from -55°C to +125°C.

Termination type is IDC for consistent and secure wiring connections. The SMT lead coplanarity is a maximum of 0.10mm for precise mounting.

This component is ideally suited for use in electronics manufacturing, telecommunications equipment, industrial control systems, and other PCB-based electronic assemblies requiring robust and reliable connector performance. It meets quality expectations without specific third-party approvals or certifications.
