Molex KK 254 Series Right Angle Through Hole Pin Header, 9 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-05-2091

Molex 22-05-2091 KK 254 Series Right Angle Through Hole Pin Header is engineered for robust PCB interconnection with a pitch of 2.54 mm and 9 male contacts arranged in a single row. Featuring a reliable 4A current capacity and rated for 250V operation, this unshrouded pin header utilizes brass contacts with tin plating to ensure excellent conductivity and corrosion resistance.

The housing is molded from white Nylon material compliant with UL 94V-0 flammability rating for enhanced safety and durability. Its right angle orientation simplifies board-to-board or wire-to-board connections, optimizing assembly layouts in electronics manufacturing.

Designed for through-hole mounting, the header has a tail pin length of 3.15 mm and mating pin length of 2.54 mm, facilitating secure soldered connections. The broad operating temperature range from -40°C to 105°C enables use in diverse industrial, commercial, and electronic applications.

This Molex KK 254 series pin header is unshrouded, providing flexibility in mating with connectors while maintaining alignment and contact integrity. Its stackable design allows end-to-end and side-to-side alignment to improve PCB space utilization.

This pin header supports up to 4A current rating for reliable electrical performance. The housing is made of durable Nylon material ensuring insulation and mechanical strength. The product features a right angle orientation for easy board-to-board or wire-to-board connection.

Termination is solder type with brass contact material and tin plating for corrosion resistance. The header has a single row of contacts with a mating pin length of 2.54 mm and tail pin length of 3.15 mm. Operating temperature ranges from -40°C to 105°C, suitable for various industrial environments.

Voltage rating is 250V accommodating common PCB connector requirements. This component is unshrouded, allowing flexible connections while maintaining pin protection.

Widely used in industrial control equipment, communication devices, instrumentation, and consumer electronics, this connector provides dependable mechanical and electrical performance.
