Molex Pico-Clasp Series Straight Surface PCB Header 5 Contacts 1 mm Pitch 1 Row Shrouded 501331-0507
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50V |
| Brand | Molex |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | Pico-Clasp |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 1mm |
Key Features
- Constructed with a nylon housing for robust insulation and durability.
- Features phosphor bronze contacts plated with tin for excellent conductivity and corrosion resistance.
- Operates reliably at temperatures ranging from -40°C to 105°C.
- Designed for surface mounting with solder termination type to ensure secure connection.
- Supports a maximum voltage of 50V and current rating of 1A, suitable for compact electronic applications.
- Includes a mating pin length of 1 mm ensuring precise connection alignment.
- This single-row, male contact connector has a shrouded design for enhanced safety and reduced risk of damage.
- Ideal for wire-to-board connections in various electronic assemblies.
Product Description
Molex 501331-0507 Pico-Clasp Series Straight Surface PCB Header is a high-density wire-to-board connector system designed for compact electronic applications requiring secure and reliable interconnections. Featuring 5 contacts arranged in a single row with a 1 mm pitch, this shrouded PCB header is engineered to provide positive lock and enhanced durability.
The connector housing is made from nylon material providing excellent insulation and mechanical strength. Contacts are crafted from phosphor bronze and plated with tin to ensure optimal conductivity and corrosion resistance. The connector supports a current rating of 1A and voltage up to 50V, suitable for a wide range of low-power electronic devices.
With an operating temperature range from -40°C to 105°C, it is reliable in diverse environmental conditions. This surface mount connector employs a solder termination type and features a mating pin length of 1 mm for precise and secure board connections.
Its shrouded design increases safety by protecting contacts from mechanical damage and accidental short circuits. The Molex Pico-Clasp series is known for its compact size and positive locking mechanism, making it ideal for use in dense electronic assemblies such as industrial control systems, communication devices, and consumer electronics.
Robust nylon housing ensures insulation and durability. Phosphor bronze contacts plated with tin provide reliable electrical performance. Designed for operating temperatures between -40°C and 105°C. Surface mounting with solder termination for secure board attachment.
Suitable for wire-to-board applications in a variety of industries. 5 contacts in a shrouded, single row, 1 mm pitch format. Voltage rating of 50V and current of 1A supports low-power circuits.
This product is manufactured in Japan ensuring high quality and reliability. It is a favored choice for engineers designing compact and robust PCB assemblies requiring dependable connector solutions. Explore more Molex components for advanced electronic connectivity needs at EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this PCB header is 1A, making it suitable for low-power electronic applications.
This connector supports a maximum voltage of 50V, suitable for various electronic circuits.
The housing is made from nylon, while the contacts are made of phosphor bronze and plated with tin for conductivity and corrosion resistance.
This model features 5 contacts arranged in a single row with a 1 mm pitch.
It uses a solder termination type, ensuring a secure connection to the PCB.
The design orientation of this connector is straight, suitable for specific mounting requirements.
This PCB header is shrouded, which enhances safety by protecting the contacts from damage and accidental short circuits.
The mating pin length is 1 mm, ensuring precise connection alignment during installation.
This product is manufactured in Japan, ensuring high quality and reliability in its construction.
It is designed for wire-to-board connections in various electronic assemblies, such as industrial control systems and consumer electronics.
This model is part of a wire-to-board connector system, ideal for compact electronic applications.
