Molex Pico-Clasp™ Series Straight Surface PCB Header 3 Contact 1 mm Pitch 1 Row Shrouded 501331-0307
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50V |
| Brand | Molex |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | Pico-Clasp |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 1mm |
Key Features
- The connector has a 1 mm pitch and a single row configuration for high-density PCB applications.
- Constructed with a nylon housing for durability and insulation.
- Contacts are male, made from phosphor bronze, and are tin plated for reliable conductivity.
- Supports a maximum current rating of 1A and a voltage rating of 50V.
- The connector is shrouded, offering positive lock and protection during mating.
- Operating temperature ranges from -40°C to 105°C, suitable for industrial applications.
- Mount type is surface, enabling surface PCB assembly.
- Termination is via soldering, ensuring secure and permanent PCB connections.
Product Description
Molex 501331-0307 Pico-Clasp™ Series Straight Surface PCB Header is a high-quality, reliable wire-to-board connector featuring a 1 mm pitch and 3 contacts arranged in a single straight row. Its nylon housing is shrouded, providing mechanical protection and secure locking to maintain reliable connections in compact PCB assemblies.
Manufactured with phosphor bronze contacts plated with tin, this male connector is designed for current ratings up to 1 ampere and voltage up to 50 volts. The connector supports solder termination and features a 1 mm mating pin length, compatible with Molex's Pico-Clasp™ series components.
Operating temperature ranges from -40°C to 105°C making it suitable for demanding industrial, electronic manufacturing, and prototype applications. The surface mount style facilitates efficient PCB assembly processes.
This connector series is ideal for applications that require high density and reliable electrical connections such as industrial equipment, instrumentation, automotive electronics, and consumer electronics devices.
The 1 mm pitch and single row design allow for compact, space-saving PCB layouts. Nylon housing ensures good insulation and resistance to environmental factors. Phosphor bronze contact material with tin plating provides excellent electrical performance and corrosion resistance.
Shrouded design ensures secure mating and minimizes risk of accidental disconnection. RoHS compliant construction ensures environmental safety.
Originating from Japan, this Molex connector is backed by stringent manufacturing standards providing consistent quality. It is widely used in electronics manufacturing, prototyping, and repair.
Explore more Molex Pico-Clasp™ PCB connectors and related electronic components at EnvMart for industrial and commercial uses.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this connector is 1 ampere.
This model has a voltage rating of 50 volts.
The housing is made from nylon, while the contacts are made from phosphor bronze and are tin plated.
The connector features a 1 mm pitch and has a single row configuration with 3 contacts.
Termination is achieved via soldering, ensuring secure and permanent PCB connections.
The operating temperature ranges from -40°C to 105°C, making it suitable for industrial applications.
This connector is shrouded, offering positive lock and protection during mating.
The mating pin length is 1 mm.
The connector originates from Japan.
It is suitable for high-density PCB applications, including industrial equipment, automotive electronics, and consumer electronics.
The shrouded design ensures secure mating and minimizes the risk of accidental disconnection.
This connector is part of the wire-to-board connector system.
