Molex MicroClasp Series Straight Surface PCB Header 8 Contact, 2 mm Pitch, 2 Row, Shrouded 55917-0810

Molex 55917-0810 MicroClasp Series Straight Surface PCB Header is a 2.00 mm pitch, 8-contact, 2-row shrouded header designed for compact and reliable wire-to-board connections in electronic assemblies. Manufactured with a robust polyester housing, this connector ensures durability while allowing space savings on printed circuit boards.

The MicroClasp™ series incorporates a unique inner positive lock mechanism that provides latch protection and secure retention with an audible click during mating. This design minimizes accidental disconnections and improves overall connection reliability.

With brass contact material plated with tin, this header guarantees low insertion forces, high conductivity, and optimal corrosion resistance. It supports continuous current loads of up to 3 amperes, making it suitable for a variety of industrial, electronic, and communication equipment applications.

Designed for surface mount assembly with solder termination, the header features a contact pitch of 2 mm and a tail pin length of 3.2 mm and mating pin length of 2 mm. The contact gender is male, and the connector system is wire-to-board, supporting 2 rows of connections for versatile PCB layout options.

This connector is rated for operating temperatures between -40°C and 105°C, ensuring stable performance under varying environmental conditions typical in industrial and commercial electronics.

Shrouded housing provides protection and prevents connector damage. Inner positive lock enhances secure mating and retention. Supports current rating of 3A for reliable electrical performance. Brass contacts with tin plating for conductivity and corrosion resistance.

Surface mount type with solder termination for PCB applications. Operating temperature range from -40°C to 105°C suits industrial environments. 2 mm pitch and 2-row configuration optimize PCB space usage. Male contact gender suitable for wire-to-board interfaces.

This Molex MicroClasp PCB header is ideal for electronic manufacturing, automation systems, instrumentation, and communication equipment requiring dependable, compact interconnections. The product fits within the category of PCB Headers in the Electronics Components sector.
