Cinch Straight Edge Connector PCB, 49-Contacts, 2.54 mm Pitch, 2 Row, Solder Termination BA000010000CE00

Free Delivery in India | Lowest Global Shipping Charges

Cinch Straight Edge Connector PCB, 49-Contacts, 2.54 mm Pitch, 2 Row, Solder Termination BA000010000CE00

Name: Cinch Straight Edge Connector PCB, 49-Contacts, 2.54 mm Pitch, 2 Row, Solder Termination BA000010000CE00
Brand: Cinch
SKU: 160333
Price: 34.21 USD
Availability: InStock



Category Edge Connector Brand Cinch Condition New

Specifications

Country of Origin	United States
Brand	Cinch
Orientation	Straight
Current	3A
Model	BA000010000CE00
Mount Type	PCB
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold over Nickel
Number of Contacts	49
Card Type	Edge

Key Features

This edge connector features a straight orientation suitable for PCB applications.
It contains 49 contacts arranged in two rows with a 2.54 mm pitch.
Contacts are made of brass with gold over nickel plating for durability and conductivity.
The connector supports up to 3A current and operates between -55°C and 105°C.
Housing is constructed of fiberglass reinforced polyethylene terephthalate providing robustness and insulation.
Includes a polarizing key for proper alignment and keying way of Yes.
Termination type is solder, offering secure and traditional connector mounting.
Complies with UL94V-0 rated polyester insulation for safety standards.

Product Description

The Cinch BA000010000CE00 Straight Edge Connector is an industrial-grade edge connector designed for PCB mounting applications. Featuring 49 contacts arranged in 2 rows with a 2.54 mm pitch, it offers reliable electrical connections in demanding electronic and power connector use cases.

Manufactured with brass contacts plated in gold over nickel, the connector ensures excellent conductivity and resistance to corrosion. The fibreglass reinforced polyethylene terephthalate housing provides high durability and electrical insulation, rated UL94V-0 for fire resistance.

This edge connector supports a current rating of 3A and operates efficiently within a temperature range of -55°C to 105°C, making it suitable for various industrial, electronic manufacturing, and laboratory environments.

Designed for solder termination with 0.156 in (3.96 mm) dip solder tails, it includes a polarising key to prevent incorrect mating and features keying functionality for secure installation. Its straight orientation makes it ideal for PCB edge applications, compatible with IBM PC AT™ standards.

The connector's robust design and high-quality materials make it well-suited for use in electronics components, power connectors, and computing-related Edge Connector applications in industrial and manufacturing sectors.

This connector is a high-quality component for electronics and power connection. Offers excellent mechanical and electrical reliability with gold-plated contacts. Suitable for industrial, electronic assembly, manufacturing, and laboratory use.

Polarising key ensures correct mating and assembly safety. Robust housing material and UL94V-0 insulation rating provide enhanced safety and durability. Explore more connectors and electronic components in EnvMart’s comprehensive electronics category for your industrial and commercial needs.
