Wurth Elektronik 401B Series PCB Terminal Block, 8-Contact, 5 mm Pitch, Through Hole Mount, 1 Row, 16A, 450V AC 691401700008B
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 450V ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Vertical |
| Current | 16A |
| Length | 42.54mm |
| Model | 691401700008B |
| Depth | 14mm |
| Width | 13mm |
| Mount Type | Through Hole |
| Series | 401B |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | RoHS, cULus, VDE |
| Number of Contacts | 8 |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 2.08mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 14AWG |
Key Features
- Supports a current rating of 16 amperes ensuring effective power transfer.
- Designed for vertical orientation with a single row and through-hole mounting.
- Compatible with wire sizes ranging from 0.2 to 2.08 mm² (24 to 14 AWG).
- Operates safely up to 450 volts AC voltage rating.
- Constructed with green color coded insulation for easy identification.
- Complies with RoHS, cULus, and VDE standards for safety and environmental compliance.
- Manufactured in China as part of the 401B series from Wurth Elektronik.
Product Description
Wurth Elektronik 691401700008B PCB Terminal Block is a durable, high-quality component engineered for secure and efficient electrical connections on printed circuit boards. Designed with 8 contacts arranged in a single row, this terminal block offers a compact 5 mm pitch spacing, ideal for applications where board space is limited yet high current capacity is required.
The terminal block supports a rated current of 16 amperes, providing reliable conductivity for various industrial, electronic, and power distribution applications. Its vertical orientation and through-hole mount construction ensure stable mechanical and electrical mounting on PCBs.
Wire compatibility ranges from 0.2 mm² to 2.08 mm², or 24 to 14 AWG, making this terminal block versatile for different conductor sizes used in electronics assembly. The unit can withstand a voltage rating up to 450 V AC, suitable for a wide range of electrical circuits requiring secure terminal connections.
Its green insulation color enhances visual identification during assembly and maintenance, while compact dimensions of 42.54 mm length, 13 mm width, and 14 mm depth contribute to an efficient footprint on the PCB.
Manufactured under Wurth Elektronik's 401B series, this terminal block meets rigorous RoHS, cULus, and VDE certification standards to ensure safety, quality, and compliance with global regulations.
Supports 16A current rating for robust electrical performance. Five-millimeter pitch provides tight contact spacing for PCB design efficiency. Through-hole mounting guarantees mechanical stability on circuit boards. Wire size flexibility supports 0.2 to 2.08 mm² conductors.
Conforms to RoHS, cULus, and VDE standards. Single-row, vertical orientation configuration. Compact 42.54 x 13 x 14 mm dimensions enable efficient board use.
This PCB Terminal Block is widely used in power connectors for electronics manufacturing, industrial automation, instrumentation, and electrical control panels. For further product options, browse the Wurth Elektronik terminal block series and related PCB terminal solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 16 amperes, ensuring effective power transfer in various applications.
The terminal block operates safely up to a voltage rating of 450 volts AC.
The dimensions are 42.54 mm in length, 13 mm in width, and 14 mm in depth.
It is compatible with wire sizes ranging from 0.2 mm² to 2.08 mm² (24 to 14 AWG).
This model features through-hole mounting, ensuring stable mechanical and electrical connections on PCBs.
It has a compact pitch of 5 mm, allowing for tight contact spacing on the PCB.
It complies with RoHS, cULus, and VDE standards for safety and environmental compliance.
This model features 8 contacts arranged in a single row.
It is designed for vertical orientation, which is suitable for various PCB layouts.
It is manufactured in China as part of the Wurth Elektronik 401B series.
The insulation is green, which aids in visual identification during assembly and maintenance.
This terminal block is part of the Wurth Elektronik 401B series.
