TDK Unshielded Wirewound Surface Mount Inductor 1 μH ±10% 380 mA 1210 Package B82422A1102K100

TDK B82422A1102K100 is an unshielded wirewound surface mount inductor featuring a ferrite core and 1 μH inductance suitable for various electronic applications. Its compact 1210 package allows easy surface mounting on printed circuit boards, making it ideal for space-constrained designs.

This inductor offers a maximum DC current rating of 380 mA and operates reliably within a temperature range of -55°C to 125°C. The ±10% inductance tolerance ensures steady performance and predictable circuit behavior.

The component complies with the stringent AEC-Q200 automotive standard, making it suitable for automotive and industrial electronics where reliability is critical. With a high self-resonant frequency of 320 MHz and a minimum quality factor of 20, it maintains signal quality and minimizes losses at high frequencies.

The device is designed with wirewound construction on a ferrite core, combining durability with stable inductance values. It is moulded to provide robust mechanical strength and solder terminations enable straightforward integration into PCB assemblies using standard reflow or wave soldering processes.

Supplied in tape and reel packaging, the B82422A1102K100 supports efficient automated assembly in manufacturing environments. Its unshielded design accommodates applications where electromagnetic shielding is not required or is provided externally.

High quality wirewound construction with ferrite core for reliable performance. 1210 package size suitable for surface mounting on PCBs. Inductance tolerance of ±10% ensures consistent electrical characteristics. Maximum operating temperature up to 125°C for reliable operation in demanding environments.

High resonance frequency of 320 MHz and minimum quality factor of 20 improve signal integrity. Compliant with automotive standard AEC-Q200 for use in automotive electronics. Supplied in tape and reel packaging ready for automated assembly.

Solder termination style for easy integration on printed circuit boards. No shielding, providing stable inductance in compact design.

This surface mount inductor is suited for applications in automotive electronics, industrial equipment, consumer electronics, and communication devices requiring precise inductive components. The combination of high quality materials with automotive compliance ensures longevity and performance reliability under various operating conditions.
