onsemi Zener Diode 47V 5W Through Hole 2-Pin Case 017AA 1N5368BG
Specifications
| Country of Origin | China |
|---|---|
| Brand | onsemi |
| Height | 3.68mm |
| Length | 8.89mm |
| Model | 1N5368BG |
| Finish | All external surfaces are corrosion resistant and leads are readily solderable |
| Gross Weight | 0.7 gram (approx) |
| Mount Type | Through Hole |
| Series | 1N53 |
| Maximum Operating Temperature | 200°C |
| Case | Void-free, transfer-molded, thermo-setting plastic |
| Package Type | Case 017AA |
| Minimum Operating Temperature | -65°C |
| Polarity | Cathode indicated by color band. When operated in zener mode, cathode will be positive with respect to anode |
| Mounting Position | Any |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 5W |
| Diode Configuration | Single |
| Maximum Reverse Leakage Current | 500nA |
| Nominal Zener Voltage Vz | 47V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 25Ω |
Key Features
- This diode features a nominal Zener voltage of 47V with a tolerance of 5 percent.
- It supports a maximum power dissipation of 5 watts for reliable voltage regulation.
- The package is an axial-lead, transfer-molded plastic with corrosion resistant finish.
- Designed to operate within a temperature range from -65°C to 200°C.
- The diode offers low maximum reverse leakage current of 500nA and a maximum Zener impedance of 25Ω.
- Its polarity is clearly indicated by a cathode color band for correct installation.
- Suitable for industrial and electronic circuit voltage regulation applications.
- RoHS compliant and manufactured in China.
Product Description
onsemi 1N5368BG Zener Diode is a high-quality semiconductor voltage regulator diode with a nominal Zener voltage of 47 volts and 5 watt power dissipation capacity, housed in a robust 2-pin Case 017AA through hole package.
This diode series features silicon-oxide passivated junctions that ensure tight electrical parameters and superior operating performance. The axial-lead, transfer-molded plastic package is void-free and thermo-setting, offering excellent protection in various environmental conditions.
Key electrical characteristics include a maximum Zener impedance of 25 ohms and a reverse leakage current limited to 500 nanoamperes, ensuring efficient voltage regulation and minimal system losses. The diode has a wide operating temperature range from -65°C to 200°C, suitable for a variety of industrial environments.
The external surfaces are corrosion resistant with readily solderable leads, facilitating reliable assembly in electronic circuits. Polarity is marked by a cathode color band, with the cathode positive relative to the anode in Zener mode. The mounting position can be arbitrary, simplifying installation.
This device complies with RoHS environmental standards and is manufactured in China. Its compact dimensions (length 8.89mm and height 3.68mm) and lightweight design (approx. 0.7 grams) make it suitable for compact layouts and applications requiring stable voltage regulation such as power supplies, industrial electronics, and instrumentation.
This diode features a nominal Zener voltage of 47V with a tolerance of 5 percent. It supports a maximum power dissipation of 5 watts for reliable voltage regulation. The package is an axial-lead, transfer-molded plastic with corrosion resistant finish.
Designed to operate within a temperature range from -65°C to 200°C. The diode offers low maximum reverse leakage current of 500nA and a maximum Zener impedance of 25Ω. Its polarity is clearly indicated by a cathode color band for correct installation.
Suitable for industrial and electronic circuit voltage regulation applications. RoHS compliant and manufactured in China. Discover more Semiconductor components and Zener Diodes on EnvMart for your industrial and electronic projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal Zener voltage of this diode is 47V with a tolerance of 5 percent.
This model supports a maximum power dissipation of 5 watts.
It is designed to operate within a temperature range from -65°C to 200°C.
The maximum reverse leakage current is limited to 500nA.
The maximum Zener impedance is 25Ω.
The polarity is indicated by a cathode color band, which shows that the cathode will be positive relative to the anode when operated in Zener mode.
This diode is housed in a 2-pin Case 017AA through hole package made of transfer-molded plastic.
The dimensions are approximately 8.89mm in length and 3.68mm in height.
It supports through hole mounting and can be installed in any position.
Yes, this diode complies with RoHS environmental standards.
It is suitable for industrial and electronic circuit voltage regulation applications.
The approximate weight of this diode is 0.7 grams.
