Samtec HPF Series 6-Contact 1 Row 5.08 mm Pitch Straight Through Hole PCB Socket HPF-06-01-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1.2kV |
| Brand | Samtec |
| Orientation | Straight |
| Model | HPF-06-01-T-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | HPF |
| Termination | Through-hole, surface mount |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Power Socket |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Connector System | Board-to-Board |
| Contact System | Power Eye |
Key Features
- Constructed with a liquid crystal polymer housing for durability.
- Features beryllium copper alloy contacts plated with tin for reliable conductivity.
- Operates effectively from -55°C to 105°C temperature range.
- Designed for vertical orientation and board-to-board connector applications.
- Complies with RoHS standards ensuring environmental safety.
Product Description
Samtec HPF-06-01-T-S is a high-quality PCB socket in the HPF Series, designed as a 6-contact, single-row connector with a 5.08 mm pitch. Its through hole mounting and solder termination enable robust and reliable board-to-board electrical connections for power applications. The housing is made from liquid crystal polymer, delivering excellent mechanical strength and stability in demanding industrial environments.
The socket's contacts are crafted from beryllium copper alloy and plated with tin, ensuring superior conductivity and corrosion resistance. Rated for 1.2 kV operating voltage, this connector supports power eye contact system technology for enhanced performance. It withstands temperature extremes from -55°C to 105°C, making it suitable for industrial, electronic components manufacturing, and testing applications.
This PCB socket is designed with a straight, vertical orientation perfect for power socket needs in electronic component assemblies. Its compliance with RoHS reflects adherence to global environment-friendly manufacturing standards.
Liquid crystal polymer housing material enhances durability and heat resistance. Beryllium copper alloy contacts with tin plating guarantee reliable electrical performance. Supports a voltage rating of 1.2 kV for power connectivity.
Operating temperature range from -55°C to 105°C suits harsh industrial conditions. Through hole termination offers secure soldering for PCB reliability. Vertical orientation suitable for board-to-board connector systems.
RoHS compliance assures environmental safety and reduced hazardous substances.
Ideal for industrial electronics production, laboratory testing, manufacturing, and assembly lines, this Samtec HPF Series PCB socket provides dependable performance and long service life. Explore additional Samtec connectors and PCB Sockets in the Electronics Components category at EnvMart for complete power and connector solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This socket has a voltage rating of 1.2 kV, making it suitable for power connectivity applications.
It operates effectively within a temperature range of -55°C to 105°C, suitable for harsh industrial conditions.
The contacts are made from beryllium copper alloy and are plated with tin, ensuring reliable conductivity and corrosion resistance.
This model features through hole mounting, which allows for secure soldering on the PCB for reliable connections.
The pitch of this connector is 5.08 mm, which is standard for many PCB applications.
The HPF-06-01-T-S socket has a total of 6 contacts, designed for board-to-board connections.
It is designed for straight orientation, which is ideal for vertical board-to-board connector applications.
Yes, it complies with RoHS standards, ensuring it meets environmental safety requirements by reducing hazardous substances.
This socket uses solder termination, which provides a robust connection for PCB applications.
The housing is constructed from liquid crystal polymer, which provides excellent mechanical strength and stability.
It is ideal for industrial electronics production, laboratory testing, manufacturing, and assembly lines.
It supports a board-to-board connector system, making it suitable for various electronic component assemblies.
