Samtec HTSW Series Straight Through Hole Pin Header 5 Contacts 2.54 mm Pitch 1 Row Unshrouded HTSW-105-07-G-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.3A |
| Model | HTSW-105-07-G-S |
| Mount Type | Through Hole |
| Special Features | Suitable for most high-temperature board processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | HTSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.54mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with a liquid crystal polymer housing for high temperature resistance.
- Features phosphor bronze contact material with gold plating for reliable connectivity.
- Supports a current rating of 4.3 A and voltage rating of 550 V.
- Designed with a straight orientation and solder termination through-hole mount.
- Operates in temperatures ranging from -55°C to 125°C, suitable for harsh environments.
- Tail pin length is 2.54 mm and mating pin length is 5.84 mm for secure connections.
- Contact system uses a 0.025" (0.635 mm) square post design compatible with standard PCBs.
- Ideal for board-to-board connector applications in electronics assembly.
Product Description
Samtec HTSW-105-07-G-S is a high-quality straight through hole pin header designed for reliable board-to-board connections in electronic assemblies. It features 5 male contacts arranged in a single row with a 2.54 mm pitch, making it compatible with standard PCB layouts.
The housing material is liquid crystal polymer, chosen for excellent high temperature resistance ensuring durability in industrial and manufacturing environments.
Contacts are made of phosphor bronze with gold plating that enhances conductivity and corrosion resistance, supporting a current capacity of 4.3 amperes and voltage rating up to 550 volts. This product operates efficiently in temperature extremes from -55°C to 125°C.
The pin header mounts through-hole with solder termination, offering robust mechanical and electrical connections. Tail pins measure 2.54 mm length and mating pins 5.84 mm, providing secure engagement with mating connectors.
This pin header is unshrouded to facilitate flexible cable and connector configurations and is suitable for most high-temperature board processing requirements. Constructed with liquid crystal polymer housing for temperature durability.
Phosphor bronze contact with gold plating ensures conductivity and corrosion resistance. 5 contacts at 2.54 mm pitch in single row straight orientation. Supports 4.3 A current and 550 V voltage with operating temperature from -55°C to 125°C.
Through hole solder termination type with 2.54 mm tail pin length. Ideal for board-to-board applications in electronics manufacturing and assembly. Unshrouded design for versatile connector usage.
This connector is widely used in industrial electronics, power distribution, instrumentation, and control systems where reliable electrical interconnections are critical. It supports robust performance under harsh environmental conditions including temperature variations and mechanical stress.
Explore more high-quality connectors and PCB components from leading brands to enhance your electronic designs and manufacturing reliability on EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 4.3 A and a voltage rating of 550 V.
The contacts are arranged with a pitch of 2.54 mm.
The housing is constructed from liquid crystal polymer, which provides high temperature resistance.
It features a through-hole termination type with solder termination.
The tail pin length is 2.54 mm and the mating pin length is 5.84 mm.
It operates efficiently in temperatures ranging from -55°C to 125°C.
This model has 5 male contacts arranged in a single row.
The contacts are made of phosphor bronze with gold plating for enhanced conductivity.
It is designed as an unshrouded connector, allowing for flexible cable and connector configurations.
It is ideal for board-to-board connector applications in electronics assembly, particularly in industrial electronics and control systems.
The contact system uses a 0.025" (0.635 mm) square post design compatible with standard PCBs.
The country of origin for this pin header is India.
