Samtec HTSW Series Straight Through Hole Pin Header 12 Contacts 2.54 mm Pitch 2 Row Unshrouded HTSW-106-07-G-D

Samtec HTSW-106-07-G-D is a straight through hole pin header designed with 12 male contacts arranged in 2 rows and a 2.54 mm pitch. The contact system uses 0.025" (0.635 mm) square posts made from phosphor bronze with gold plating, ensuring dependable signal integrity and long-lasting performance.

The housing is constructed from liquid crystal polymer, offering excellent heat resistance and durability, suitable for most high-temperature board processing applications. Operating temperatures range from -55°C to 125°C, making it ideal for demanding industrial electronics environments.

This unshrouded connector has a current rating of 4.3A and voltage rating of 550V, supporting power and signal transmission on printed circuit boards. The connector system is board-to-board with through-hole solder termination, providing strong mechanical retention and electrical continuity.

Tail pin length measures 2.54 mm with a mating length of 5.84 mm for compatibility with standard sockets and connectors. Its straight orientation facilitates easy assembly and routing in electronic assemblies.

Applications include commercial electronics, industrial automation, electronic manufacturing, and electrical testing setups. The pin header is RoHS compliant, meeting environmental and safety directives.

This pin header operates at a current rating of 4.3A ensuring robust electrical performance. The housing is made from liquid crystal polymer suitable for high-temperature board processing. The contacts are male phosphor bronze plated with gold for excellent conductivity and corrosion resistance.

The connector features a straight orientation and is unshrouded, allowing easy access and solder termination. It supports a voltage rating of up to 550V and operates within a temperature range from -55°C to 125°C. Termination is via through-hole soldering to provide secure mechanical and electrical connections.

The pin header’s tail pin length is 2.54 mm and mating pin length is 5.84 mm, matching industry-standard dimensions. This component is ideal for board-to-board connections in industrial, electronic, and manufacturing applications.

It is RoHS compliant and suitable for high-reliability uses in harsh environments. Explore further high-quality PCB connectors and electronic components with Samtec products on EnvMart.
