TDK 47 nF Multilayer Ceramic Capacitor, 100V dc, ±10 % Tolerance, Surface Mount, X8R Dielectric CGA4J3X8R2A473K125AB

TDK CGA4J3X8R2A473K125AB multilayer ceramic capacitor offers 47 nF capacitance with a voltage rating of 100V dc and ±10 % tolerance. This surface mount device features X8R dielectric material enabling operation up to a maximum temperature of 150°C, making it suitable for demanding automotive environments.

The capacitor is built in a compact 0805 package (2 mm length, 1.25 mm width, and 1.25 mm height) complying with automotive standard AEC-Q200, ensuring high reliability and endurance for engine room conditions and peripheral circuits.

Excellent DC bias characteristics and capacitance stability within ±15 % at maximum rated temperature make it perfect for smoothing and decoupling applications, especially with advanced components like IGDT, SiC, and GaN used in high temperature scenarios.

The surface mount termination facilitates automated PCB assembly processes, with packaging supplied on tape and reel for high volume manufacturing efficiency. Typical uses include automotive module sensors, power electronics, and any industrial device requiring stable capacitance under harsh conditions.

Features X8R dielectric suitable for high temperature up to 150°C. Surface mount termination ensuring easy PCB assembly. Complies with automotive standard AEC-Q200 for reliability. Compact 0805 package size with dimensions 2mm x 1.25mm x 1.25mm.

Ideal for smoothing and decoupling in automotive and high temperature environments. Capacitance change within ±15 % at maximum operating temperature. Suitable for applications with IGDT, SiC, and GaN components.

This capacitor is essential for automotive electronics and industrial applications demanding robust performance and reliability. Explore more Multilayer Ceramic Capacitors and electronic components on EnvMart.
