Abracon 28.6363 MHz Crystal Unit Surface Mount 4-Pin 3.2 mm x 2.5 mm x 1 mm ±20 ppm Frequency ABM8G-28.63636MHZ-18-D2Y-T

Abracon ABM8G-28.63636MHZ-18-D2Y-T Crystal Unit is a high reliability surface mount frequency control component designed for electronic circuits requiring precise oscillation at 28.6363 MHz. Its compact 4-pin surface mount package measures 3.2 mm in length, 2.5 mm in width, and stands only 1 mm tall, making it suitable for space-constrained modern electronic devices.

This crystal unit features a frequency tolerance of ±20 ppm and operating temperature range from -40°C to 85°C, meeting the demands of industrial, communication, modem, and test equipment applications. The glass sealed construction ensures excellent long-term stability and resistance to environmental factors.

The unit's load capacitance of 18 pF and series resistance of 50Ω facilitate integration into high-density circuitry while maintaining signal integrity. It supports infrared reflow soldering processes, making it compatible with automated PCB assembly lines and mass production.

Compliance with international standards such as RoHS and REACH confirms its environmental safety and suitability in globally-regulated markets. This model is a low cost alternative within the ABM8G series, delivering reliable performance at optimized cost.

Standard frequency of 28.6363 MHz ensures precise timing. Surface mount package with 4 pins designed for PCB assembly. Compact dimensions of 3.2 mm length, 2.5 mm width, and 1 mm height. Frequency stability up to ±30 ppm for reliable performance.

Load capacitance rated at 18 pF suitable for controlled circuits. Operates across temperature range from -40°C to 85°C for industrial use. Glass sealed package enhances reliability and temperature resistance. Compliance with RoHS and REACH standards assures environmental safety.

Low series resistance of 50Ω reduces signal loss.

This Abracon Crystal Unit is ideal for use in industrial electronics, communication systems, laboratory instruments, test equipment, and other applications requiring stable and accurate frequency oscillation. EnvMart offers this product as a high quality component for precision electronic designs.
