Amphenol Communications Solutions Dubox Series Straight Through Hole PCB Header 6 Contacts 2.54 mm Pitch 1 Row 76384-306LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1kV |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Current | 3A |
| Model | 76384-306LF |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Thermoplastic |
| Contact Material | Phosphor Bronze |
| Series | Dubox |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 0.62mm |
Key Features
- The header features a glass filled thermoplastic housing for durability and high temperature resistance.
- Contact material is phosphor bronze with gold plating to ensure reliable electrical connections.
- Designed with polarization and friction lock to prevent mismating and ensure secure mating.
- Supports a current rating of 3A and voltage rating of 1kV for robust performance.
- Operates reliably in a temperature range from -65°C to 125°C suitable for industrial and instrumentation applications.
- Mating pin length is 0.62 mm, compatible with Dubox crimp connector housings.
- Mount type is through hole allowing easy PCB assembly.
- Ideal for industrial, instrumentation, medical, consumer electronics, communications, and data applications.
Product Description
Amphenol Communications Solutions 76384-306LF Dubox Series PCB Header is a high-quality straight through hole connector designed for wire-to-board applications. It features a 6-contact configuration with a standard 2.54 mm pitch arranged in a single row, providing reliable electrical connections in compact PCB layouts.
The housing is made from glass filled thermoplastic, enabling it to withstand solder reflow and wave soldering processes with high temperature tolerance from -65°C to 125°C. The contacts are manufactured from phosphor bronze and plated with gold, ensuring excellent conductivity as well as resistance to corrosion and wear.
The Dubox PCB header incorporates polarization features to avoid incorrect mating and a friction lock mechanism for secure connections, enhancing assembly reliability. Rated for 3A current and 1kV voltage, it is suitable for demanding industrial, instrumentation, medical, consumer electronics, communications, and data transfer environments.
This connector mounts through the PCB for dependable mechanical stability. The 0.62 mm mating pin length is standardized for compatibility with corresponding Dubox crimp connector housings, allowing easy integration into wire-to-board interconnection systems.
The shrouded design provides protection and reduces the risk of electrical shorts. The connectors are also end-to-end stackable to save PCB space and support flexible system designs.
High temperature resistant glass filled thermoplastic housing. Gold plated phosphor bronze contacts for reliable signal transmission. Polarization and friction lock to prevent mismating and secure connections. Current rating of 3A and voltage withstand of 1kV.
Operating temperature range from -65°C to 125°C. Through hole mount type with 0.62 mm mating pin length. Ideal for industrial, instrumentation, medical, consumer electronics, communications and data applications. This product is manufactured in France and meets the quality and reliability standards expected in demanding electronic component applications.
Explore more PCB Headers and related products from Amphenol Communications Solutions and browse our Electronics Components category for comprehensive industrial-grade connectors and PCB interconnection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a current rating of 3A and a voltage rating of 1kV, making it suitable for various applications.
This PCB header operates reliably within a temperature range of -65°C to 125°C.
The contacts are made from phosphor bronze and are plated with gold to ensure reliable electrical connections.
It features 6 contacts arranged in a single row.
This model utilizes a through hole mount type, allowing for easy PCB assembly.
The pitch size is 2.54 mm, which is standard for many PCB applications.
Yes, it incorporates polarization features and a friction lock mechanism to prevent mismating and ensure secure connections.
The mating pin length is 0.62 mm, compatible with Dubox crimp connector housings.
It is ideal for industrial, instrumentation, medical, consumer electronics, communications, and data applications.
This PCB header is manufactured in France.
The housing is made from glass filled thermoplastic, providing high temperature resistance and durability.
It belongs to the wire-to-board connector system, suitable for various interconnection needs.
