Amphenol Communications Solutions Dubox Series Straight Through Hole PCB Header, 3 Contact(s), 2.54 mm Pitch, 1 76384-303LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1kV |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Current | 3A |
| Model | 76384-303LF |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Thermoplastic |
| Contact Material | Phosphor Bronze |
| Series | Dubox |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 0.62mm |
Key Features
- The 2.54 mm Dubox series offers a shrouded, straight connector for secure mating.
- Constructed with glass filled thermoplastic housing for high temperature resistance.
- Phosphor bronze contacts with gold plating ensure reliable conductivity.
- Designed for through-hole mounting compatible with solder termination.
- Safe operation from temperatures ranging -65°C to 125°C.
- Supports operation up to 3 A current and withstands voltage up to 1 kV.
- Features end to end stackability to optimize PCB space.
- Polarization and friction lock prevent mismating and secure the connection.
Product Description
Amphenol Communications Solutions 76384-303LF Dubox Series Straight Through Hole PCB Header is a high-quality wire-to-board connector designed specifically for reliable interconnection in various electronic devices. This single row header features 3 male contacts spaced at a 2.54 mm pitch, ideal for precise and compact PCB applications.
The housing is made of glass filled thermoplastic material, ensuring durability and the ability to withstand solder reflow and wave solder processes without degradation. The phosphor bronze contact material with gold plating promises low contact resistance and high corrosion resistance for consistent electrical performance.
The connector supports a current rating of 3 A and operates safely within a temperature range from -65°C to 125°C, while being rated for up to 1 kV voltage. Its through-hole mount type allows for secure solder connections on PCBs, facilitating strong mechanical and electrical joint reliability.
The Dubox Series headers are shrouded on two walls and designed to be end to end stackable, enabling efficient PCB space utilization. Polarization features guarantee correct mating alignment and the friction lock mechanism provides a reliable connection preventing accidental disconnections under vibration or shock.
This connector is widely used in industrial, instrumentation, medical, consumer electronics, communications, and data transmission equipment, where precision and reliability are paramount. Manufactured in France, this product meets high-quality standards expected from Amphenol Communications Solutions.
The 2.54 mm pitch Dubox series is designed for wire-to-board applications. Housing is high temperature resistant glass filled thermoplastic. Contacts made of phosphor bronze with gold plating. Single row, 3 contacts, straight orientation, shrouded on two walls.
Rated current: 3 A, voltage: 1 kV, operating temperature: -65°C to 125°C. Through hole mount with solder termination type. Polarization prevents mismating; friction lock ensures secure mating. End to end stackable for PCB space efficiency.
Ideal for industrial, medical, communication, and consumer electronics applications. Explore more options in PCB Headers and connectors on EnvMart to meet diverse industrial and commercial electronics needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3 A.
It is rated for a maximum voltage of 1 kV.
The operating temperature range is from -65°C to 125°C.
The housing is made of glass filled thermoplastic, while the contacts are made of phosphor bronze with gold plating.
This unit features 3 male contacts.
The contacts are spaced at a pitch of 2.54 mm.
It is designed for through-hole mounting with solder termination.
Yes, it includes polarization features to prevent mismating and a friction lock to ensure a secure connection.
Yes, the Dubox Series headers are designed to be end to end stackable, optimizing PCB space.
The contacts are in a straight orientation.
This product is manufactured in France.
It is widely used in industrial, instrumentation, medical, consumer electronics, communications, and data transmission equipment.
