Amphenol Communications Solutions Dubox Series Straight Through Hole PCB Header Connector 8 Contacts 2.54 mm 76385-304LF

Amphenol Communications Solutions 76385-304LF PCB Header Connector is part of the Dubox Series designed for reliable wire-to-board interconnections in electronic assemblies. This straight through hole header features 8 male contacts arranged in 2 rows with a 2.54 mm pitch, optimized for various industrial, instrumentation, medical, consumer electronics, communications, and data applications.

The housing is manufactured from glass filled thermoplastic material, which ensures high thermal stability and resistance during solder reflow and wave soldering processes, making it suitable for harsh operating conditions. The connector system includes polarization features that prevent incorrect mating and a friction lock mechanism that secures the connection firmly on the PCB.

Contacts are crafted from phosphor bronze and plated with gold to enhance conductivity and resistance to corrosion. The connector can handle continuous current of up to 3 amperes and voltages up to 1 kilovolt, maintaining performance in demanding electrical environments. Its operating temperature range from -65°C to 125°C allows deployment in extreme climates and industrial settings.

Mounting is implemented through hole with solder termination, offering a robust mechanical and electrical bond to printed circuit boards. The compact design provides stackability end-to-end on the PCB, enabling efficient use of limited space in electronic equipment.

This PCB Header is ideal for use in a wide variety of markets including industrial automation, instrumentation, medical devices, consumer electronics, communications, and data transmission systems, where consistent performance and durability are critical.

The connector is designed for wire-to-board applications with shrouded housing for secure mating. It is constructed from glass filled thermoplastic for high temperature resistance. Contacts are made of phosphor bronze plated with gold to ensure reliable connectivity.

Rated for 3 A current and withstands voltages up to 1 kV. Operating temperature range from -65°C to 125°C suitable for industrial environments. Mount type is through hole with solder termination for durable assembly. Polarization and friction lock prevent mismating and provide secure connection.

Compact design allows end-to-end stackable mounting to save PCB space. For specialized PCB connector needs, explore the extensive range available at EnvMart’s Electronics & Electricals category.
