Samtec ERF8 Series Straight Surface PCB Socket 50-Contact 2 Row 0.8mm Pitch Solder

Samtec ERF8-025-01-L-D-RA-L-TR is a high-quality PCB Socket designed for straight surface mounting applications with 50 contacts arranged in 2 rows and a 0.8 mm pitch solder termination. It features a housing made of Liquid Crystal Polymer, offering excellent durability and mechanical strength. With a current rating of 2.2 A and a voltage capacity of 318 V, this socket reliably supports medium-power electronic systems.

The device operates efficiently within a wide temperature range from -55°C to 125°C, making it suitable for various industrial, commercial, and laboratory environments. Its 18 mm stacking height and 4.5 mm row pitch allow compact and efficient PCB layouts. The socket's bronze contacts are gold plated for optimal electrical conductivity and corrosion resistance, ensuring long-lasting performance.

Designed as a Board-to-Board connector system with a straight orientation, it provides high-speed data transmission capabilities with support for up to 28+ Gbps signal rates in the Samtec 28+ Gbps series. The rugged Edge Rate® contact technology includes a smooth broad milled contact surface, increasing the wear life and reliability of the connection. Furthermore, the series supports positions up to 200 contacts for scalable applications.

Manufactured in the United States, this PCB socket meets stringent quality requirements and is dual sourced by Hirose®, ensuring availability and quality consistency. Ideal for industrial electronics, telecommunications, networking equipment, and high-speed data applications, it provides reliable connections for complex systems.

Manufactured with Liquid Crystal Polymer housing for high durability. Supports up to 2.2 A current with a voltage rating of 318 V. Operating temperature range from -55°C to 125°C suitable for various environments. Stacking height of 18 mm and row pitch of 4.5 mm for compact PCB design.

Bronze contact material with gold plating ensures reliable conductivity and corrosion resistance. Designed for Board-to-Board connector system with straight orientation. Provides rugged Edge Rate® contact with smooth milled contact surface for enhanced wear life.

Suitable for high-speed data applications with up to 28+ Gbps signal handling. Positions support expansion up to 200 contacts in the series. Manufactured in the United States ensuring high-quality standards. Explore a wide range of PCB Socket solutions with Samtec products available at EnvMart for reliable and high-performance electronic component connections.
