Molex MicroClasp Series Straight Through Hole PCB Header 9 Contact 2 mm Pitch 1 Row Shrouded 55932-0910

Molex 55932-0910 MicroClasp Series straight through hole PCB header is a male wire-to-board connector featuring 9 contacts arranged in a single row with a 2 mm pitch. Constructed with a robust polyester housing, this shrouded PCB header is designed for reliable and secure insertion into printed circuit boards using through-hole mounting. The connector system provides low insertion and withdrawal forces thanks to its innovative terminal design, ensuring easy mating and unmating while maintaining strong retention.

This connector supports a maximum current of 3 A and a maximum voltage of 250 V, making it suitable for a variety of electronic applications. The contacts are made of tin-plated material which enhances conductivity and corrosion resistance. Operating reliably in temperatures ranging from -40°C to 105°C, it is engineered to withstand adverse environmental conditions. The housing lance system adds additional latch protection with an audible click to confirm secure connection.

The MicroClasp™ series connector's design focuses on space savings on the PCB with its 2.00 mm pitch and compact form factor. Its shrouded design helps in preventing mis-mating and mechanical damage during assembly or operation. The pin lengths, with a mating pin length of 2 mm and tail pin length of 3.2 mm, ensure a robust mechanical and electrical connection when soldered. This product is made in Japan, reflecting strict manufacturing quality controls.

Single row vertical header with 9 contacts configured at 2 mm pitch. Shrouded polyester housing enhances durability and prevents pin damage. Through-hole mounting suitable for stable PCB installation. Supports 3 A current carrying capacity at 250 V voltage rating.

Wide operating temperature range from -40°C to 105°C for reliability in harsh conditions. Tin plated male contacts guarantee conductivity and corrosion resistance. Housing lance system provides positive latch protection with audible mating click.

Compact 2 mm pitch system saves PCB space in electronic designs.

This Molex MicroClasp 55932-0910 PCB header is ideal for industrial, electronic manufacturing, and repair applications requiring secure wire-to-board connections. It is widely used in communications, automotive electronics, consumer electronics, and other sectors demanding high-quality reliable connectors. For professional purchasing, explore the comprehensive range of PCB Headers and connectors available on EnvMart for enhanced project integration.
