Hirose DF11 Male Connector Housing, 2 mm Pitch, 2 Way, 2 Row Straight

Hirose DF11-6DEP-2C is a male connector housing from the DF11 Series, featuring a compact 2.00 mm pitch and a double row 2 way design. It is constructed from polyamide housing material, providing durability and reliability in electronic connection applications.

This connector housing is designed with a space-saving layout, allowing a double row of contacts to fit in the same footprint as typical single row housings, with an overall length and width of 13 mm and a depth less than 5 mm. The straight orientation and panel mount type allow for easy and secure installation in electronic assemblies.

The connector features guide ribs that prevent incorrect insertion or twisting during mating, ensuring a proper connection every time. A friction locking mechanism secures the plug firmly to its mating socket, while mounting ears help retain the connector on panels with thickness between 1.0 mm and 1.6 mm.

This DF11 series connector housing is widely used in digital cameras, LCD displays, digital video recorders, car navigation systems, access control units, and precision measurement devices where multiple signals are required in a compact form factor.

Compact, space-saving 2 mm pitch with double row contacts. Friction locking mechanism ensures secure connection. Polyamide housing material for durability. Guide ribs prevent incorrect mating. Mounting ears provide secure panel retention.

Suitable for various portable and industrial electronic devices. Measures 13 mm length x 13 mm width, less than 5 mm depth.

Choose Hirose DF11-6DEP-2C Connector Housing for reliable and compact electronic component connections. Explore more connectors and electronic components at EnvMart for your industrial and commercial projects.
