Wurth Elektronik PCB LAN Ethernet Transformer, 1 Output, Solder Termination, 15.88 mm x 13.95 mm, -40°C to 85°C 74990111211
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Length | 15.88mm |
| Width | 13.95mm |
| Mount Type | PCB |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Standards/Approvals | IEEE 802.3u |
| Insertion Loss | -1dB |
| Minimum Operating Frequency | 1MHz |
| Maximum Operating Frequency | 100MHz |
| Turns Ratio | 1:1 |
| Turns Ratio1 | 1 |
Key Features
- Operates between -40°C and 85°C suitable for various thermal environments.
- Compact size with dimensions of 15.88 mm length and 13.95 mm width for space-efficient PCB integration.
- Complies with IEEE 802.3u standard ensuring compatibility with Ethernet protocols.
- Insertion loss of -1 dB supports efficient signal integrity for frequencies from 1 MHz up to 100 MHz.
- Solder termination type offers secure electrical connection and durability.
- Manufactured in China with high-quality standards from Wurth Elektronik.
Product Description
Wurth Elektronik 74990111211 PCB LAN Ethernet Transformer is a high-quality transformer designed specifically for LAN Ethernet applications. This product features a single output and is intended for PCB mounting with solder termination, making it ideal for embedded computing devices, modems, hubs, routers, switches, M2M communication, IoT devices, and industrial Ethernet solutions such as EtherCAT.
Operating reliably within a temperature range of -40°C to 85°C, it ensures stability under various environmental conditions. The compact dimensions of 15.88 mm length and 13.95 mm width facilitate efficient PCB layout designs without compromising performance.
Designed following IEEE 802.3u standards, this LAN Ethernet transformer supports frequencies from 1 MHz to 100 MHz with an insertion loss of -1 dB, preserving signal integrity and network performance. The 1:1 turns ratio enables proper impedance matching aligned with Ethernet communication needs.
The solder termination ensures a robust and lasting connection with the PCB, suitable for industrial and commercial electronic assemblies. Made in China by Wurth Elektronik, a renowned provider of electronic components, this transformer meets strict quality and reliability criteria.
Operates between -40°C and 85°C for robust environmental tolerance. Measures 15.88 mm in length and 13.95 mm in width for space optimization. IEEE 802.3u compliance for Ethernet transformer standards. Insertion loss of -1 dB to maintain signal quality over the specified frequency range.
1:1 turns ratio for proper electrical balance and performance. Solder termination ensures durable mounting to PCB. Suitable for embedded computing, network hubs, routers, M2M, IoT, and EtherCAT applications.
This product is ideal for engineers and designers working on electronic and communication systems requiring reliable LAN connectivity and Ethernet signal transformation. Explore more from Wurth Elektronik and related LAN Ethernet Transformers on EnvMart for industrial and laboratory applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model measures 15.88 mm in length and 13.95 mm in width, making it suitable for compact PCB layouts.
It operates reliably within a temperature range of -40°C to 85°C, suitable for various thermal environments.
It complies with the IEEE 802.3u standard, ensuring compatibility with Ethernet protocols.
The insertion loss is -1 dB, which supports efficient signal integrity for frequencies from 1 MHz to 100 MHz.
It has a turns ratio of 1:1, which enables proper impedance matching for Ethernet communication.
This unit features a solder termination type, providing a secure electrical connection to the PCB.
It is ideal for embedded computing devices, modems, hubs, routers, switches, M2M communication, IoT devices, and EtherCAT applications.
This model has a single output, designed for specific LAN Ethernet applications.
It is manufactured in China by Wurth Elektronik, adhering to high-quality standards.
The transformer operates within a frequency range of 1 MHz to 100 MHz, making it suitable for various Ethernet applications.
This unit is designed for PCB mounting, making it easy to integrate into electronic assemblies.
The 1:1 turns ratio ensures proper electrical balance and performance for Ethernet signal transformation.
