Wurth Elektronik WE-GF 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 22 μH ±10% 110 mA Idc Q:30 744764122

Wurth Elektronik 744764122 WE-GF 1210 Shielded Wirewound Surface Mount Inductor is a high-frequency choke designed for electronic circuit applications requiring stable inductance and low interference. It features a ferrite core and a precise inductance value of 22 μH with a tolerance of ±10%, supporting a maximum DC current of 110 mA.

This surface mount component has a robust wirewound construction, providing excellent quality factor (Q=30) and shielding to reduce electromagnetic interference, making it suitable for HF amplifiers, oscillators, transponders, and LC filter circuits. Its compact 1210 package size ensures ease of integration into modern PCB layouts.

The inductor's operating temperature range of -40°C to 105°C ensures reliable performance in diverse industrial and commercial environments. It exhibits a maximum DC resistance of 3.7 ohms and a maximum self-resonant frequency of 25 MHz, making it suitable for high-frequency applications.

Packaging is provided in tape and reel format, facilitating efficient automated component placement in manufacturing processes. The product is moulded for enhanced durability and manufactured in China to meet quality standards, although it does not have automotive certification.

Typical industrial and laboratory use cases include signal processing, power regulation, RF circuits, and filtering tasks in telecommunications, instrumentation, and embedded systems.

This surface mount inductor offers a maximum DC resistance of 3.7 ohms ensuring efficient performance. It is shielded to reduce electromagnetic interference for high-frequency applications. The component has a compact package size 1210 with dimensions 2.9 mm length, 2.5 mm depth, and 2.2 mm height.

Its operating temperature ranges from -40°C to 105°C for reliable use in various environments. The inductor features a high-quality wirewound construction with a ferrite core for improved inductance stability. The specified minimum quality factor (Q) is 30, suitable for HF amplifiers and LC filter circuits.

It includes tape and reel packaging, ideal for automated PCB assembly processes. Designed for applications such as oscillators, tuners, and transponders requiring stable inductance. This series WE-GF is moulded for durability and longevity under demanding conditions.

Made in China with assured manufacturing standards but without specific automotive certifications. Explore more high-quality electronic components including Inductors and surface mount devices at EnvMart for advanced industrial and electronic design needs.
