TDK Shielded Wirewound Surface Mount Inductor 68μH ±20/±30 % 1 A Dc Current 6045 Package VLS6045EX-680M
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 6mm |
| Model | VLS6045EX-680M |
| Depth | 6mm |
| Packaging | Reel |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 6045 |
| Maximum DC Current | 1A |
| Maximum DC Resistance | 310mΩ |
| Inductance Tolerance | ±20/±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded design suitable for power circuits.
- Constructed with high-quality ferrite material for enhanced magnetic shielding.
- Compact 6045 package size with dimensions 6 mm length, 6 mm depth, and 4.5 mm height.
- Maximum operating temperature of 105°C and minimum operating temperature of -40°C.
- Surface mount termination style for efficient PCB mounting.
- Inductance tolerance of ±20 to ±30 percent ensures consistent performance.
- Maximum DC resistance of 310mΩ for optimized current handling.
- Compliant with RoHS standards for environmental safety.
Product Description
TDK VLS6045EX-680M is a high-quality shielded wirewound surface mount inductor featuring a magnetically shielded ferrite core design. This 6045 package inductor offers an inductance of 68μH with a tolerance of ±20/±30%, suitable for various power circuit applications requiring stable inductance performance and electromagnetic interference suppression.
The component supports a maximum DC current of 1A and operates reliably in a temperature range from -40°C to 105°C. The low DC resistance of 310mΩ optimizes power efficiency and reduces energy losses during operation. Its compact size, measuring 6 mm in length, 6 mm in depth, and 4.5 mm in height, allows for high-density mounting on PCBs using surface mount technology (SMT).
Manufactured using a ferrite core material, the inductor ensures excellent magnetic shielding and durability with a moulded wirewound construction. This component complies with RoHS environmental standards, making it appropriate for use in environmentally conscious electronic manufacturing.
This inductor is widely used in consumer electronics including televisions, game consoles, set-top boxes, and audiovisual equipment, providing effective noise suppression and energy storage for power conversion circuits. It is packaged on reels to facilitate automated PCB assembly processes.
Magnetically shielded design suitable for power circuits. High magnetic shield construction using ferrite magnetic material. Compact 6045 package with precise dimensions for dense PCB layouts. Reliable operation from -40°C to 105°C temperature range.
Low maximum DC resistance of 310mΩ for efficient current flow. Surface mount termination style for ease of assembly. RoHS compliant for environmental safety standards. Wide application in TVs, game devices, set-top boxes, and audiovisual equipment.
Packaged on reel for SMT automation compatibility. Explore our Electronics Components category on EnvMart for more Surface Mount Inductors and passive components from leading brands like TDK.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 68μH with a tolerance of ±20/±30%.
It can handle a maximum DC current of 1A.
The dimensions of the 6045 package are 6 mm in length, 6 mm in depth, and 4.5 mm in height.
The operating temperature range is from -40°C to 105°C.
This inductor uses a ferrite core material for enhanced magnetic shielding.
The maximum DC resistance is 310mΩ, optimizing current handling efficiency.
It features a surface mount termination style for efficient PCB mounting.
Yes, it complies with RoHS standards for environmental safety.
It is packaged on reels to facilitate automated PCB assembly processes.
It is suitable for use in consumer electronics such as televisions, game consoles, and audiovisual equipment.
The inductor features a wirewound construction, which enhances its performance characteristics.
This model belongs to the VLS-EX series of inductors.
