Wurth Elektronik 3-Contact 3.5 mm Pitch Through Hole PCB Terminal Block, Horizontal Orientation, 10A, 300V AC 691508110303

Wurth Elektronik 691508110303 PCB Terminal Block is a high-quality 3-contact terminal block designed for printed circuit boards with a 3.5 mm pitch. It features a through hole mount and a horizontal wire entry orientation, facilitating easy and secure connections in electronic assemblies.

The terminal block uses a pressure clamp system tightened via an M2 screw and tin-plated brass clamp, ensuring robust, vibration-resistant conductor contact. The housing is manufactured from grey UL94-V0 rated LCP material, known for excellent flame retardance and mechanical stability.

This model supports wire gauges from 30 AWG (0.05 mm²) up to 16 AWG (1.33 mm²) and is rated for a current of 10 amperes at 300 volts AC. Its compact form factor, with dimensions of about 12.5 mm length, 17.6 mm width, and 12.2 mm depth, makes it suitable for dense PCB layouts.

The single-row design with three contacts includes alignment pegs to aid accurate positioning on PCBs during soldering processes. It complies with major standards including VDE, RoHS, and cULus, making it a reliable choice for industrial, commercial, and laboratory electronic applications.

Pressure clamp connection system with M2 screw. Supports wire size ranges 30 to 16 AWG. Current rating of 10A at 300V AC voltage. UL94-V0 flame retardant grey LCP housing. Dimensions approximately 12.5 x 17.6 x 12.2 mm. Single row with 3 contacts and horizontal wire entry.

Complies with VDE, RoHS, and cULus standards.

This terminal block is ideal for electronics manufacturing, power and control systems, automation equipment, and prototyping environments. Its proven design offers safe, durable, and easy-to-install PCB connections.
