onsemi 5-Channel Linear Voltage Regulator TO-220 3-Pin 2.2A 37V LM317TG

onsemi LM317TG 5-Channel Linear Voltage Regulator in TO-220 3-pin package is designed for versatile voltage regulation applications requiring adjustable output ranging from 1.25 V to 37 V and output current capacity up to 2.2 A. This linear regulator operates via a closed feedback loop to maintain a steady voltage across output terminals, providing reliable and precise voltage control.

The device offers robust internal protections including thermal overload protection to prevent overheating and internal short circuit current limiting for safety. The output transistor safe-area compensation feature enhances device durability under various load conditions.

Constructed as a through-hole package with a compact form factor (dimensions approximately 15.75 mm height, 10.28 mm length, and 10.28 mm width), it is suitable for integration in various electronics and power management circuits.

Operating temperature ranges from -55°C up to 150°C, ensuring suitability for industrial and automotive environments compliant with the AEC-Q100 standard. The device supports positive polarity voltage regulation with outstanding line regulation of 0.04 %/V and load regulation of 25 mV, providing stable voltage output despite input and load fluctuations.

Typical applications include on-card regulation, programmable output regulation, and precision current regulation by using an external resistor to set current limits. Its Pb-Free construction aligns with environmental compliance requirements.

This device includes internal thermal overload protection. Features internal short circuit current limiting. Incorporates output transistor safe-area compensation. Designed with a TO-220 3-pin through-hole package. Operation temperature range spans from -55°C to 150°C.

Suitable for positive polarity voltage regulation applications. Compliance with RoHS and automotive standard AEC-Q100. Adjustable output voltage ranging from 1.25V to 37V. Line regulation of 0.04 %/V ensures stable output under varying input.

Load regulation of 25 mV maintains voltage stability under load changes.

Ideal for industrial, automotive, laboratory, and electronic equipment power regulation needs, the onsemi LM317TG offers a dependable solution for both standard and specialized voltage regulation requirements. Explore more power management ICs and Voltage Regulators in the EnvMart catalog for comprehensive industrial electronics solutions.
