Renesas Electronics Operational Amplifier CA3130EZ, 50 kHz Gain Bandwidth Product, 8-Pin PDIP, 6-16V Supply Voltage CA3130EZ

Free Delivery in India | Lowest Global Shipping Charges

Renesas Electronics Operational Amplifier CA3130EZ, 50 kHz Gain Bandwidth Product, 8-Pin PDIP, 6-16V Supply Voltage CA3130EZ

Name: Renesas Electronics Operational Amplifier CA3130EZ, 50 kHz Gain Bandwidth Product, 8-Pin PDIP, 6-16V Supply Voltage CA3130EZ
Brand: Renesas Electronics
SKU: 136788
Price: 3.31 USD
Availability: InStock



Category Operational Amplifier Brand Renesas Electronics Condition New

Specifications

Country of Origin	China
Brand	Renesas Electronics
Height	4.95mm
Length	10.16mm
Model	CA3130EZ
Width	7.11mm
Mount Type	Through Hole
Series	CA3130
Output Current	45mA
Maximum Operating Temperature	125°C
Package Type	PDIP
Minimum Operating Temperature	-55°C
Number Of Channels	1
Standards/Approvals	RoHS
Pin Count	8
Maximum Supply Voltage	16V
Minimum Supply Voltage	6V
GBP - Gain Bandwidth Product	50kHz
Input Bias Current	50 pA
Vos - Input Offset Voltage	15 mV
Slew Rate	30V/μs
Input Offset Current	30 pA
CA3130EZ Intersil, Op Amp, 6 → 15 V, 8-Pin PDIPBrand	Intersil

Key Features

High input impedance with low input current enabled by MOSFET input stage.
Gain bandwidth product of 50 kHz ensuring suitable frequency response.
Wide supply voltage range from 6 V to 16 V for flexible power configurations.
High slew rate of 30 V/μs supports fast signal transitions.
Operating temperature range from -55°C to 125°C for broad environmental tolerances.
Single channel device in a through-hole 8-pin PDIP package.
RoHS compliant device manufactured in China.
Input offset voltage typical value of 15 mV and input bias current of 50 pA.

Product Description

Renesas Electronics CA3130EZ operational amplifier is a high-performance BiMOS amplifier featuring a MOSFET input stage providing high input impedance and low input bias current, ideal for precision analog applications.

This single-channel operational amplifier offers a gain bandwidth product of 50 kHz and supports a supply voltage range of 6 V to 16 V, making it suitable for a wide variety of electronic circuits and single-supply designs.

The device's slew rate of 30 V/μs and output current of 45 mA enable swift signal response and reliable driving capability for various loads.

Designed in a standard 8-pin PDIP through-hole package, the CA3130EZ offers ease of use in prototyping and production, conforming to RoHS environmental directives. With an extensive operating temperature range from -55°C to 125°C, it is capable of reliable operation in harsh industrial and commercial environments.

Input offset voltage and input bias current ratings ensure high precision and minimal drift, suitable for sensitive amplification tasks. The CA3130EZ is manufactured in China and complies with industry quality standards ensuring dependable performance.

High input impedance with low input current enabled by MOSFET input stage. Gain bandwidth product of 50 kHz for precise frequency response. Wide supply voltage range from 6 V to 16 V. Slew rate of 30 V/μs for fast output response.

Operating temperature range from -55°C to 125°C. Single channel, 8-pin PDIP through-hole package. RoHS compliant and manufactured in China. Input offset voltage of 15 mV and input bias current of 50 pA typical. Output current up to 45 mA.

Compact dimensions supporting space-conscious designs.

This Operational Amplifier is commonly used across industrial electronics, laboratory instruments, signal conditioning, and communication equipment for amplification and active filtering applications.
