Texas Instruments Operational Amplifier 3 MHz, 8-Pin SOIC, 5V-15V Supply TL081CDR

Texas Instruments TL081CDR is a high-performance operational amplifier featuring JFET input and bipolar output, designed for low noise and distortion in audio and signal processing industries. This device operates over a wide supply voltage range from ±5 V up to ±15 V allowing flexible circuit design. With a gain bandwidth product of 3 MHz and a high slew rate of 13 V/μs, it is capable of handling fast transient signals effectively.

The 8-pin SOIC surface mount package provides a compact footprint suitable for modern PCB layouts, with dimensions 4.9 mm length, 3.91 mm width, and 1.58 mm height. The device maintains an input offset voltage of 20 mV and an input offset current of only 2 nA, minimizing error in precision applications. It is characterized by a typical low noise of 18 nV/√Hz at 1 kHz and a total harmonic distortion as low as 0.003%, ensuring high-fidelity amplification of analog signals.

Operating over a temperature range of 0°C to 70°C and meeting the automotive AEC-Q100 standard, the TL081CDR is suitable for demanding environments in industrial, audio, laboratory instrumentation, and automotive electronics.

JFET Input Op Amp for low bias and noise. Wide supply voltage range: ±5 to ±15 V. Typical gain bandwidth product of 3 MHz. High slew rate of 13 V/μs for fast response. Low total harmonic distortion at 0.003% typical. Compact 8-pin SOIC package for surface mounting.

Operates between 0 and 70°C ambient temperature. Compliance with automotive standard AEC-Q100. Low offset voltage and input offset current for precision. Ideal for industrial, laboratory, audio, and automotive uses.

This Operational Amplifier is a key component in audio amplification, signal conditioning, data acquisition, and other electronic circuit designs where precision and speed are critical. Explore our extensive catalog of semiconductors and amplifiers at EnvMart for compatible components and accessories.
