Texas Instruments Operational Amplifier 1 MHz 8-Pin SOIC 15V TL062ID
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | TL062ID |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TL062 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 15V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 20 nA |
| Vos - Input Offset Voltage | 9 mV |
| Slew Rate | 3.5V/μs |
| Input Offset Current | 10 nA |
Key Features
- Low power consumption JFET input operational amplifier.
- Dual channel design with 8 pins for compact mounting.
- Operates over supply voltage range from 5V to 15V.
- Gain bandwidth product of 1 MHz for reliable signal amplification.
- Slew rate of 3.5V/μs for fast response to input changes.
- Input bias current of 20 nA for low input current drift.
- Operating temperature range from -40°C to +85°C.
- Compact SOIC surface mount package measuring 4.9mm x 3.91mm x 1.58mm.
Product Description
Texas Instruments TL062ID is a JFET input operational amplifier designed for low power consumption and high performance in dual channel applications. Featuring a gain bandwidth of 1 MHz and supplied in an 8-pin SOIC package, it integrates easily into surface mount PCB designs.
The amplifier operates with a supply voltage range from 5V to 15V, facilitating flexible use across various electronic circuits. The device offers a fast slew rate of 3.5 V/μs, ensuring rapid response to input signals, making it suitable for audio processing, signal conditioning, and sensor interfacing.
Additional technical features include a low input bias current of 20 nA, an input offset voltage of 9 mV, and input offset current of 10 nA, contributing to accurate signal amplification with minimal error. It is rated for operation in temperatures ranging from -40°C to 85°C, supporting use in industrial and commercial environments.
The compact dimensions of 4.9 mm length, 3.91 mm width, and 1.58 mm height in SOIC package help minimize PCB space, optimizing layout efficiency for embedded systems and portable electronics.
Texas Instruments TL062ID operational amplifiers are widely used in industrial control systems, instrumentation, automotive electronics, and laboratory equipment requiring low power and moderate frequency amplification.
Low power consumption JFET input operational amplifier. Dual channel design with 8 pins for compact mounting. Operates over supply voltage range from 5V to 15V. Gain bandwidth product of 1 MHz for reliable signal amplification.
Slew rate of 3.5V/μs for fast response to input changes. Input bias current of 20 nA for low input current drift. Operating temperature range from -40°C to +85°C. Compact SOIC surface mount package measuring 4.9mm x 3.91mm x 1.58mm.
Input offset voltage of 9 mV and input offset current of 10 nA for precision applications. Explore more products in the Operational Amplifier category at EnvMart for a variety of electronics components suitable for industrial and laboratory applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the TL062ID is 1 MHz, ensuring reliable signal amplification in various applications.
This model operates over a supply voltage range from 5V to 15V, providing flexibility for different electronic circuits.
The operational amplifier comes in a compact SOIC package measuring 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
The slew rate of this operational amplifier is 3.5 V/μs, allowing for a fast response to input changes.
The input bias current for the TL062ID is 20 nA, which helps in minimizing input current drift.
This operational amplifier operates within a temperature range of -40°C to 85°C, making it suitable for industrial and commercial environments.
The TL062ID features a dual channel design, allowing for two independent signal processing paths.
The input offset voltage for this operational amplifier is 9 mV, contributing to its precision in signal amplification.
This operational amplifier is designed for surface mounting, which facilitates compact PCB layouts.
The input offset current for the TL062ID is 10 nA, which aids in achieving accurate signal amplification.
The TL062ID is manufactured in India, ensuring compliance with local manufacturing standards.
The TL062ID is part of the TL062 series of operational amplifiers, which are known for their low power consumption and high performance.
