Phoenix Contact Surge Protector 300A 50V DIN Rail Mount TTC Series 2906831

The Phoenix Contact 2906831 surge protector is designed for industrial and commercial applications requiring robust surge suppression with a voltage protection rating of 50 volts and a maximum surge current capacity of 300 amperes. This device mounts conveniently on standard DIN Rails, making it ideal for electrical, automation, and control panel installations.

Equipped with a mechanical status indicator, it provides reliable visual signalling of its protective status without requiring additional auxiliary power. The device supports an impulse discharge current of 150 amperes, allowing it to quickly respond to transient surges and protect sensitive equipment.

With a compact form factor measuring 6.2 mm in width, 92 mm in length, and 69.5 mm in depth, this surge protector offers space-saving benefits in tight panel configurations. It meets the IP20 ingress protection rating, offering protection against access to hazardous parts and ingress of solid objects larger than 12.5 mm.

Operating effectively within a temperature range of -40°C to 60°C, it ensures dependable performance in diverse industrial and environmental conditions. The surge protector complies with internationally recognized standards EN 61643-21 and IEC 61643-21, reflecting its conformity to safety and performance requirements.

Voltage protection rating of 50 volts ensures effective protection against power surges. Maximum surge current capacity of 300 amperes for high energy transient suppressions. DIN Rail mount type allows easy installation in electrical panels.

Impulse discharge current rated at 150 amperes for rapid response to surges. Compact dimensions: width 6.2 mm, length 92 mm, depth 69.5 mm for space saving. IP20 rated enclosure provides basic protection against solid objects.

Operating temperature range from -40°C to 60°C for reliable performance in various environments. Features mechanical status indicator for signalling without auxiliary power. Complies with EN 61643-21 and IEC 61643-21 standards for surge protection devices.

Manufactured in Germany ensuring high quality and durability.

This surge protector is suitable for use in industrial, electrical automation, manufacturing, and commercial power distribution systems where protection from voltage surges is critical. It is engineered for reliability and ease of maintenance, with error-free replacement of protective plugs.
