Celduc Solid State Relay SO942960, 25 A Load Current, DIN Rail Mount, 280 V AC Load, 265 V AC/DC Control SO942960

Celduc SO942960 Solid State Relay is engineered for high-performance single-phase applications, accommodating a maximum load current of 25 A and a load voltage of up to 280 V AC. The relay features a DIN Rail mount design optimized for quick fitting into electrical distribution and control panels.

The SO9 series utilizes TMS2 technology with thyristor output to ensure long service life and reliable operation under various load conditions. It includes voltage protection via varistor (VDR) components at both input and output, providing exceptional immunity against electrical interference and surge conditions.

This solid state relay supports a wide control voltage range from 20 to 265 V AC/DC with a regulated control current, allowing flexible integration in industrial automation and control systems. It employs zero cross switching technology to minimize electrical noise and electromagnetic interference, making it suitable for sensitive applications.

Additional features include a green LED input display for visual status monitoring, screw terminal connections for secure wiring, and an IP20 rating to protect against solid objects and limited ingress of dust. Its compact form factor with dimensions 44.8 x 44.8 x 30 mm fits well in control panels where space is at a premium.

The device meets key international standards and approvals including RoHS, EAC, cURus, VDE, UKCA, CSA, and CE, ensuring compliance with global regulatory requirements. It operates reliably in temperatures ranging from -55°C up to 100°C, suitable for a range of industrial and commercial environments.

Supports maximum load current of 25 amperes for robust operation. Designed for DIN Rail mounting ensuring easy installation. Maximum load voltage of 280 V AC suitable for various loads. Control voltage range up to 265 V AC/DC for flexible control applications.

Features zero cross switching for reduced electrical noise. Equipped with green LED input display for operation status indication. Compact dimensions with length and width of 44.8 mm and height of 30 mm. Has a low on state resistance of 16 milliohms, enhancing efficiency.

Operating temperature range from -55°C to 100°C supports harsh environments. Includes screw terminal type and IP20 protection rating for safety and reliability.

This solid state relay is ideal for industrial automation, manufacturing processes, HVAC control, water treatment systems, and other commercial electrical control applications requiring reliable switching and minimal maintenance. It must be installed on a heatsink to ensure proper thermal management and maximum longevity.
