Celduc SO4 Series Solid State Relay 125A Load, 480V AC Load, DIN Rail Mount, 10V Control SO469020

Celduc SO469020 Solid State Relay with a maximum load current of 125A and maximum load voltage of 480V AC is designed for efficient power control in industrial environments. This DIN rail mount relay supports precise phase angle control of resistive loads. Its compact size with dimensions of 59.4mm length, 44.8mm width, and 30mm height makes installation convenient in control panels.

Featuring zero cross switching, it minimizes transient surges and electrical noise during switching. The relay incorporates integrated varistors for protection against voltage spikes, enhancing durability and reliability. The output utilizes a triac, enabling smooth AC load switching with low on-state resistance of 16mΩ and low off-state leakage current of 2mA.

The SO4 series relay is rated for operation within a wide temperature range from -55°C to 100°C and holds international approvals including cURus, EAC, RoHS, VDE, UKCA, CE, and CSA, ensuring compliance with multiple industrial standards. The IP20 protection index protects internal components from solid objects, making it suitable for controlled indoor use.

Installation is simplified with screw terminal connections and two spring-technology pull-out connectors, allowing secure and easy wiring. Manufactured in France, this relay is ideal for applications in electrical automation, industrial machinery, HVAC controls, and manufacturing process control.

With its robust design and phase control functionality, this solid state relay meets demanding industrial requirements for safe and efficient power switching. Suitable for controlling resistive load power using phase angle control.

Integrated varistors provide protection against overvoltage. Equipped with two spring-technology pull-out connectors for easy installation. Switching function uses zero cross switching to reduce electrical noise. Compact dimensions: 59.4mm length, 44.8mm width, and 30mm height.

High IP20 protection rating ensures safe operation in industrial environments. Constructed for operation in temperatures ranging from -55°C to 100°C. Output type is a triac, suitable for AC load switching. Reliable screw terminal type connection for sturdy contact.

France manufactured solid state relay optimized for industrial and automation use. Explore more Solid State Relays and reliable industrial electrical components at EnvMart for diverse technical applications.
