Celduc SP-ST-SL Series Solid State Relay Through Hole Mount 2A Load 30V Load 30V Control STD03505
Specifications
| Country of Origin | France |
|---|---|
| Brand | Celduc |
| Height | 15.8mm |
| Length | 29.2mm |
| Model | STD03505 |
| Width | 13mm |
| Mount Type | Through Hole |
| Output type | Current/Voltage |
| Series | SP-ST-SL |
| Contact Configuration | SPST |
| Terminal type | Through Hole |
| Maximum Load Current | 2A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 30V |
| Minimum Load Voltage | 0V |
| Minimum Control Voltage | 12V |
Key Features
- Supports load currents up to 2 amperes for reliable switching.
- Operates with a maximum load voltage of 30 volts.
- Designed for through hole mounting providing secure installation.
- Features SPST contact configuration for single-pole, single-throw switching.
- Compatible with control voltages ranging from 12 to 30 volts.
- Compact dimensions of 29.2mm length, 15.8mm height, and 13mm width.
- Contains integral RC network for noise suppression in SLA series models.
- Built-in surge clipper enhances performance in SLD series versions.
Product Description
Celduc STD03505 is a SP-ST-SL series solid state relay designed for industrial and electronic applications requiring reliable switching of loads up to 2 amperes and 30 volts. The relay supports a through hole mount format, facilitating robust mechanical and electrical connections in circuit boards. It is suitable for automation, signal conditioning, and control systems where compact and durable relays are essential.
This model features a SPST (single-pole, single-throw) contact configuration with an output type capable of handling both current and voltage. The relay operates with control voltages from 12 to 30 volts and supports load voltages from 0V up to a maximum of 30V, making it versatile for various DC control circuits.
The relay has a compact design with precise dimensions of 29.2mm in length, 15.8mm in height, and 13mm in width, ensuring it occupies minimal circuit board space. The Celduc SP-ST-SL series incorporates an integral RC network in SLA variants to reduce electrical noise and a built-in surge clipper in SLD variants to protect against transient voltage spikes, thereby enhancing longevity and operational stability.
Compliant with RoHS environmental standards, the device aligns with modern ecological safety requirements. Manufactured in France, this relay assures high quality and precision engineering.
Supports 2 ampere maximum load current for demanding applications. Through hole mounting provides secure and stable installation. SPST contact configuration enables effective single circuit control. Control voltage rating ranges from 12 to 30 volts for flexibility.
Compact form factor suitable for dense PCB designs. Integral RC network and surge clipper improve electrical performance. RoHS certified ensuring compliance with hazardous substance restrictions. Manufactured in France to high quality standards.
This Celduc solid state relay is widely used in industrial automation, electrical control systems, signal conditioning circuits, and manufacturing equipment control. Its reliable switching and durable design make it suitable for commercial and industrial applications requiring solid state relay technology.
Explore more Solid State Relay options at EnvMart to find complementary electrical and automation products for your project.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This solid state relay supports a maximum load current of 2 amperes.
It can handle a maximum load voltage of 30 volts.
The relay operates with control voltages ranging from 12 to 30 volts.
This model features a SPST (single-pole, single-throw) contact configuration.
The relay has compact dimensions of 29.2mm in length, 15.8mm in height, and 13mm in width.
It is designed for through hole mounting, providing secure installation on circuit boards.
The output type of this relay is capable of handling both current and voltage.
Yes, it contains an integral RC network for noise suppression in SLA series models.
Yes, it is compliant with RoHS environmental standards, ensuring it meets hazardous substance restrictions.
This relay is manufactured in France, ensuring high quality and precision engineering.
It is widely used in industrial automation, electrical control systems, and signal conditioning circuits.
The relay includes a built-in surge clipper to protect against transient voltage spikes, enhancing operational stability.
