Wurth Elektronik 14-Way IDC Connector Male for Cable, 2 Row, 1A, 250V AC, 2.54mm Pitch, WR-BHD Series 61201425821

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 14-Way IDC Connector Male for Cable, 2 Row, 1A, 250V AC, 2.54mm Pitch, WR-BHD Series 61201425821

Name: Wurth Elektronik 14-Way IDC Connector Male for Cable, 2 Row, 1A, 250V AC, 2.54mm Pitch, WR-BHD Series 61201425821
Brand: Wurth Elektronik
SKU: 133637
Price: 6.3 USD
Availability: InStock



Category IDC Connector Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	250V ac
Brand	Wurth Elektronik
Orientation	Straight
Current	1A
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Copper Alloy
Series	WR-BHD
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	14
Contact Gender	Male
Connector Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

Features 14 contacts arranged in 2 rows for reliable connections.
Gold-plated copper alloy contacts provide enhanced conductivity and corrosion resistance.
Shrouded design ensures secure mating and protection against accidental contact.
Utilizes 2.54mm pitch in the WR-BHD series for compatibility with standard IDC cables.
Constructed with polybutylene terephthalate housing for durability and electrical insulation.
Operates effectively between -40°C and 105°C for a wide range of environments.
Termination by Insulation Displacement Contact (IDC) type for fast and reliable installation.
Connector gender is male, suitable for cable mounting applications.

Product Description

Wurth Elektronik 61201425821 is a high-quality 14-Way IDC connector designed for cable mounting applications, featuring a 2-row contact arrangement. It carries a current rating of 1A with a voltage capacity of 250V AC, making it suitable for various electronics and electrical projects requiring precise and reliable connections.

The connector uses the WR-BHD series with a 2.54mm pitch, ensuring compatibility with standard IDC ribbon cables. Its gold-plated copper alloy contacts provide superior conductivity and resistance to corrosion, enhancing signal integrity. The polybutylene terephthalate housing adds robust insulation and mechanical strength to the component.

This IDC connector features a shrouded male configuration with straight orientation, designed to protect contacts and prevent misalignment during connection. The termination type is IDC, allowing quick and secure wire attachment without stripping, which is beneficial in assembly-line production and field installations.

Operating temperature ranges from -40°C to 105°C, enabling use in industrial, laboratory, manufacturing, and commercial electronic environments with varied climatic conditions.

Applications include PCB connection in electronic devices, cable harnesses, and system interconnects. Its design facilitates easy integration into ribbon cable assemblies and wire-to-board interfaces.

14 contacts in 2 rows for reliable data and power transmission. Gold-plated copper alloy contacts for enhanced durability and performance. Shrouded housing securing safe and accurate connections. Polybutylene terephthalate material for excellent electrical insulation.

Wide operating temperature range allows versatile environmental use. Compatible with IDC ribbon cabling for efficient termination. Male connector gender with cable mount for versatile application. Straight orientation optimizes board layout and cable routing.

This product is classified under IDC Connectors in the Electronics & Electricals category at EnvMart, suitable for professionals in electronics design and manufacturing requiring dependable cable connection solutions.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model has a current rating of 1A and a voltage capacity of 250V AC, making it suitable for various electronics applications.

The connector utilizes a 2.54mm pitch, which ensures compatibility with standard IDC ribbon cables, facilitating efficient termination.

It features a polybutylene terephthalate housing for insulation and mechanical strength, with gold-plated copper alloy contacts for enhanced conductivity and corrosion resistance.

The operating temperature range is from -40°C to 105°C, allowing it to function effectively in various environmental conditions.

This IDC connector has 14 contacts arranged in 2 rows, providing reliable connections for data and power transmission.

It utilizes an Insulation Displacement Contact (IDC) termination type, allowing for fast and reliable wire attachment without stripping.

Yes, it is designed as a male connector suitable for cable mounting applications, ensuring secure connections.

The connector has a straight orientation, which optimizes board layout and cable routing during installation.

The shrouded design of the connector ensures secure mating and protects against accidental contact, enhancing safety during use.

It is suitable for applications such as PCB connection in electronic devices, cable harnesses, and system interconnects.

The connector is manufactured in Taiwan, which is noted in its specifications.

This model belongs to the WR-BHD series, which is designed for compatibility with standard IDC cables.
