Nexperia Silicon Junction Switching Diode Single 225 mA 3-Pin SC-70 250 V 250 mW BAS21W,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Silicon Junction Switching Diode Single 225 mA 3-Pin SC-70 250 V 250 mW BAS21W,115

Name: Nexperia Silicon Junction Switching Diode Single 225 mA 3-Pin SC-70 250 V 250 mW BAS21W,115
Brand: Nexperia
SKU: 133215
Price: 0.05 USD
Availability: InStock



Category Switching Diodes Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	2.2mm
Model	BAS21W,115
Width	1.35mm
Mount Type	Surface
Series	BAS21
Maximum Operating Temperature	150°C
Package Type	SC-70
Sub Type	Silicon Junction
Minimum Operating Temperature	-55°C
Pin Count	3
Maximum Power Dissipation Pd	250mW
Diode Configuration	Single
Peak Non-Repetitive Forward Surge Current Ifsm	2.5A
Maximum Forward Voltage Vf	1.25V
Peak Reverse Recovery Time trr	4ns
Maximum Forward Current If	225mA
Maximum Peak Reverse Repetitive Voltage Vrrm	250V
onsemi Silicon Junction, Single, 200 mA, 2-Pin 250 V SOD-323 BAS21HT1GBrand	onsemi

Key Features

This diode supports surface mount technology for easy PCB integration.
It features a low forward voltage drop of 1.25 V for efficient conduction.
The device has a peak reverse recovery time of 4 ns, suitable for high-speed switching.
Maximum power dissipation is 250 mW, allowing stable performance within thermal limits.
Operating temperature ranges from -55°C to 150°C, ensuring reliability in varied environments.
Its compact dimensions (length 2.2 mm, width 1.35 mm, height 1.1 mm) support high-density circuit designs.
The diode has a peak non-repetitive forward surge current of 2.5 A for transient robustness.
It is well-suited for electronic, industrial, and power applications requiring precise small-signal switching.

Product Description

Nexperia BAS21W,115 is a Silicon Junction Switching Diode designed for high-speed switching and low leakage current applications. It is supplied in a compact SC-70 surface mount package with 3 pins, delivering a maximum forward current of 225 mA and a maximum peak reverse repetitive voltage of 250 V.

This diode offers a low forward voltage of 1.25 V and a fast peak reverse recovery time of 4 ns, making it ideal for use in high-frequency circuits, signal processing, and power regulation circuits in industrial, automotive, and electronic equipment.

The device operates reliably over a wide temperature range of -55°C to 150°C and dissipates a maximum power of 250 mW. Its compact size with dimensions of 2.2 mm length, 1.35 mm width, and 1.1 mm height supports high density PCB layouts and miniaturized electronic designs.

Features include:. Supports customised high density circuit designs. Low leakage current combined with high voltage tolerance. High switching speeds due to fast recovery time. Compact SC-70 package suitable for surface mount technology.

Wide operating temperature range ensures use in harsh environments. Robust peak surge current capability enhances durability against transients. Typical applications include electronic circuits requiring small signal switching, industrial and automotive electronics, and power supply regulation circuits.

Set contains one Nexperia BAS21W,115 silicon junction switching diode in SC-70 package. Explore more semiconductors and Switching Diodes with EnvMart for reliable industrial and electronic components.
