| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.91mm |
| Length | 4.56mm |
| Model | 1N5229BTR |
| Mount Type | Through Hole |
| Series | 1N52 |
| Maximum Operating Temperature | 200°C |
| Package Type | SOD-27 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 20mA |
| Maximum Reverse Leakage Current | 5μA |
| Nominal Zener Voltage Vz | 4.3V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 22Ω |
onsemi 1N5229BTR Zener Diode is a single element 4.3 V nominal Zener voltage component designed for use in voltage regulation and protection circuits. It comes in a 2-pin through-hole SOD-27 package with a height of 1.91 mm and length of 4.56 mm.
This diode dissipates a maximum of 500 mW power and features a maximum Zener impedance of 22 ohms to provide stable voltage clamping characteristics. The device can operate reliably within a temperature range of -65°C to 200°C, making it suitable for industrial and electronic applications requiring temperature resilience.
The typical test current is 20 mA, and the maximum reverse leakage current is limited to 5 μA to minimize leakage losses. This general purpose Zener diode is part of the trusted 1N52 series from onsemi, though it is not specifically qualified for automotive standards.
Applications include industrial electronics, power supply voltage regulation, circuit protection against voltage spikes, and other semiconductor-related uses. The diode features a nominal Zener voltage of 4.3 V. Supports maximum power dissipation of 500 mW.
Configured as a single element device. Through-hole mount type with SOD-27 package. Operating temperature from -65°C to 200°C. Maximum reverse leakage current is 5 μA. Maximum Zener impedance of 22 ohms. Test current is 20 mA.
Height 1.91 mm and length 4.56 mm. Not certified for automotive applications. Explore more semiconductors and discrete components in the EnvMart electronics category for industrial and commercial electronic design projects.
Explore more products in our Zener Diodes category.
