| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1mm |
| Length | 2.7mm |
| Model | MM3Z18VT1G |
| Mount Type | Surface |
| Series | MM3ZxxxT1G |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 300mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 50nA |
| Nominal Zener Voltage Vz | 18V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 45Ω |
| Typical Voltage Temperature Coefficient | 16mV/K |
| Surface Mount case | SOD-323 (SC-76) |
| Diodes Inc, 24V Zener Diode 2.5% 500 mW SMT 2-Pin SOD-323FBrand | DiodesZetex |
onsemi MM3Z18VT1G is a single element Zener diode manufactured for stable voltage regulation applications. Featuring a nominal Zener voltage of 18 V, this diode dissipates a maximum power of 300 mW. The compact 2-pin SOD-323 surface mount package makes it suitable for a wide range of industrial and commercial electronic assemblies requiring tight space constraints.
Operating efficiently over a wide temperature range from -65°C up to 150°C, this diode provides reliable and precise voltage regulation. Its maximum Zener impedance of 45 ohms and low maximum reverse leakage current of 50 nA reinforce its suitability for sensitive circuits.
The MM3ZxxxT1G series device has a test current of 5 mA and maintains a typical voltage temperature coefficient of 16 mV/K, ensuring stable operation with temperature variations. The device does not come with specific automotive standards but adheres to industrial-quality semiconductor norms.
This Zener diode is designed for applications in power supply regulation, voltage reference, and protection circuits within electronics manufacturing, industrial equipment, instrumentation, and control systems.
The surface mount SOD-323 (SC-76) package type provides compact dimensions, making the diode ideal for modern PCB assembly in commercial and laboratory settings. It supports the needs of electronic device fabrication requiring robust semiconductor components.
The diode features a 2-pin surface mount design for PCB assembly. Maximum power rating of 300 mW supports moderate power applications. Operating temperature span ensures durability across environments. Minimal leakage current improves circuit reliability and efficiency.
The device provides voltage regulation through the 18 V nominal rating. Compact 2.7 mm by 1 mm size optimizes board footprint. Supports semiconductor applications in electronics, industrial, and laboratory domains. Meets MM3ZxxxT1G series specifications for design consistency.
