Wurth Elektronik Wirewound Surface Mount Inductor 10 μH ±30 % 3.4 A Idc 0804 Shielded Ferrite Core 744071100
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 8mm |
| Length | 8mm |
| Depth | 4.3mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 10μH |
| Package/Case | 0804 |
| Maximum DC Current | 3.4A |
| Maximum DC Resistance | 35mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 24MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Standards/ApprovalsIEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS |
| IEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS |
Key Features
- Features a ±30% inductance tolerance for flexible design applications.
- Supports continuous operation at temperatures from -40°C to 125°C.
- Constructed with a wirewound inductor design to ensure low DC resistance of 35 mΩ.
- Complies with automotive standard AEC-Q200 and is RoHS and REACH compliant.
- Uses ferrite core material with magnetic shielding to reduce leakage fields.
- Optimized for portable power, DC/DC converters, embedded PCs, and telemetric applications.
- Offers a maximum self-resonant frequency of 24 MHz for high-frequency performance.
- Termination style is surface mount for ease of PCB assembly.
Product Description
Wurth Elektronik model 744071100 is a wirewound surface mount inductor with an inductance of 10 μH ±30% tolerance, designed for high current applications up to 3.4 A DC. The inductor is housed in a compact 0804 package measuring 8 mm by 8 mm with a depth of 4.3 mm, making it suitable for space-constrained PCB layouts.
Featuring a ferrite core with magnetic shielding, this component minimizes electromagnetic interference, providing low leakage fields crucial in sensitive electronic circuits. It conforms to automotive AEC-Q200 standards and environmental compliance including RoHS and REACH directives, ensuring reliability and sustainability.
Operating over a wide temperature range from -40°C to 125°C, the WE-TPC series inductor is ideal for portable power applications such as PDAs, digital cameras, PCMCIA cards, embedded PCs, and mobile data collection devices. The low DC resistance of 35 mΩ ensures energy efficiency and reduced heat generation during operation.
The inductor offers a maximum self-resonant frequency of 24 MHz, supporting applications requiring high-frequency signal filtering or DC-DC conversion. Surface mount termination facilitates modern assembly methods with tape and reel packaging, optimizing production throughput.
Inductance tolerance of ±30% provides design tolerance flexibility. Shielded ferrite core reduces electromagnetic interference. Meets IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B standards. Suitable for harsh environments with operating temperatures from -40°C to 125°C.
Compact 0804 case size with surface mount termination. Tape and reel packaging supports automated production.
This Surface Mount Inductor is well suited for industrial, consumer electronics, telecommunications, automotive electronics, and other sectors where miniaturized, reliable inductors are required. Explore the range of Wurth Elektronik inductors on EnvMart for your advanced electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 10 μH with a tolerance of ±30%.
It can handle a maximum DC current of 3.4 A.
The dimensions of the 0804 package are 8 mm in length, 8 mm in width, and 4.3 mm in depth.
The operating temperature range is from -40°C to +125°C.
The maximum self-resonant frequency is 24 MHz.
It uses a ferrite core material, which is shielded to reduce leakage fields.
It complies with automotive standard AEC-Q200 and is also RoHS and REACH compliant.
It is packaged in tape and reel format, facilitating ease of PCB assembly.
This inductor features a wirewound construction design.
The maximum DC resistance is 35 mΩ.
It is optimized for portable power applications, DC/DC converters, embedded PCs, and telemetric applications.
This model meets IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, and JEDEC JS709B standards.
