Wurth Elektronik Wirewound Surface Mount Inductor 100μH 950mA Composite Iron Powder Core 744787101
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | -40°C up to +125°C |
| Height | 5mm |
| Length | 7.8mm |
| Depth | 7mm |
| Packaging | Tape & Reel |
| Series | WE-PD2 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Composite Iron Powder |
| Inductance | 100μH |
| Standards/Approvals | RoHS, REACH, JEDEC JS709B |
| Package/Case | 7850 |
| Maximum DC Current | 950mA |
| Maximum DC Resistance | 467mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 5MHz |
| Inductor Construction | Self-Centring Shielding Ring |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with self-centring shielding ring for stable inductance current.
- Shielded design compatible with surface mount technology.
- Operating temperature ranges from -40°C to +125°C.
- Inductance tolerance is ±20% with maximum DC resistance of 467mΩ.
- Suitable for reflow soldering manufacturing processes.
- Complies with automotive standard AEC-Q200 and RoHS, REACH, JEDEC JS709B certifications.
- Package type is tape and reel for efficient production integration.
Product Description
Wurth Elektronik 744787101 is a high-quality wirewound surface mount inductor featuring a composite iron powder core, engineered for use in electronic circuits requiring a 100μH inductance with a maximum DC current of 950mA.
This shielded power inductor utilizes a self-centring shielding ring design that provides stable inductance and reduces electromagnetic interference in sensitive applications. It is specifically designed for surface mount technology, facilitating automated PCB assembly with tape and reel packaging.
Its robust construction supports operating temperatures from -40°C up to +125°C, making it suitable for automotive and industrial environments complying with the AEC-Q200 standard. The inductance tolerance is ±20%, and it offers a maximum DC resistance of 467mΩ, ensuring efficiency and reliability in power management circuits.
The inductor meets environmental and safety compliances including RoHS, REACH, and JEDEC JS709B standards, confirming its suitability for modern electronic manufacturing requirements. The compact size with dimensions of 7.8mm length, 5mm height, and 7mm depth enables deployment in space-constrained applications.
Typical applications include electronic component integration in automotive systems, industrial power circuits, and consumer electronics requiring stable magnetic performances and reduced interference. The product is manufactured in China and optimized for reflow soldering processes to enhance production efficiency.
Constructed with self-centring shielding ring for stable inductance current. Shielded design compatible with surface mount technology. Operating temperature ranges from -40°C to +125°C. Inductance tolerance is ±20% with maximum DC resistance of 467mΩ.
Suitable for reflow soldering manufacturing processes. Complies with automotive standard AEC-Q200 and RoHS, REACH, JEDEC JS709B certifications. Package type is tape and reel for efficient production integration. Compact dimensions: length 7.8mm, height 5mm, depth 7mm.
Explore more Surface Mount Inductors and electronic components from Wurth Elektronik on EnvMart for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 100μH.
The maximum DC current rating for this inductor is 950mA.
It has a maximum DC resistance of 467mΩ.
The operating temperature ranges from -40°C to +125°C.
This inductor complies with RoHS, REACH, JEDEC JS709B standards, and the automotive standard AEC-Q200.
The inductor is packaged in tape and reel format for efficient production integration.
It features a self-centring shielding ring construction, which provides stable inductance and reduces electromagnetic interference.
The dimensions of this unit are 7.8mm in length, 5mm in height, and 7mm in depth.
Yes, this model is specifically designed for surface mount technology, facilitating automated PCB assembly.
The inductor uses a composite iron powder core material.
The inductance tolerance for this inductor is ±20%.
The maximum self-resonant frequency of this inductor is 5MHz.
