| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.47mm |
| Length | 5.6mm |
| Model | 1SMB5930BT3G |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 3W |
| Diode Configuration | Single |
| Test Current It | 23.4mA |
| Maximum Reverse Leakage Current | 1μA |
| Nominal Zener Voltage Vz | 16V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 10Ω |
onsemi 1SMB5930BT3G Zener Diode offers a nominal Zener voltage of 16 V and a maximum power dissipation of 3 W. The diode is designed as a voltage regulator in a compact surface mount DO-214AA package with 2 pins, ideal for seamless integration on printed circuit boards.
This diode features a single element configuration, providing reliable voltage stabilization in various electronic applications including power supplies and protective circuits.
The component operates within a wide temperature range from -65°C to 150°C, making it suitable for industrial, automotive, and commercial electronic systems where environmental conditions vary significantly.
The 1SMB5930BT3G has a test current of 23.4 mA and a maximum Zener impedance of 10 ohms, ensuring consistent voltage regulation under fluctuating load conditions.
Additionally, it complies with RoHS environmental standards and meets the automotive quality standard AEC-Q101, confirming its robustness and reliability for automotive electronics and demanding applications.
Single diode configuration designed for voltage regulation. Nominal Zener voltage of 16 V with 5% tolerance for precise voltage control. Surface mount DO-214AA package with 2 pins for easy PCB assembly. Maximum power dissipation of 3 W suitable for moderate power protection circuits.
Wide operating temperature range from -65°C to 150°C ensures reliability in harsh conditions. Low maximum reverse leakage current of 1 μA to minimize power loss. RoHS compliant and meets automotive standard AEC-Q101.
This Zener diode is ideal for use in electronic manufacturing, automotive electronics, industrial control systems, and power supply regulation. It ensures voltage stabilization and surge protection in compact surface mount packages.
Explore the broader range of semiconductor components and Zener Diodes in EnvMart for your electronic design and manufacturing needs.
