Wurth Elektronik Magnetically Shielded Wirewound Surface Mount Inductor 5.6 μH ±30 % 6 A Idc 7447714056

Wurth Elektronik 7447714056 is a magnetically shielded wirewound surface mount inductor designed for demanding electronic applications requiring high current capacity and compact size. This inductor provides an inductance of 5.6 μH with an inductance tolerance of ±30%. It supports a maximum DC current of 6 A, suitable for regulating power in switching regulators and integrated DC-DC converters used in automotive and industrial equipment.

The inductor is housed in a 1050 surface mount package measuring 10 mm length, 10 mm depth, and 5 mm height, making it ideal for compact PCB layouts. It is designed to withstand operating temperatures from -40°C to 125°C while maintaining performance stability, complying with automotive standard AEC-Q200 and IPC/JEDEC J-STD-020D reliability standards.

This unit features magnetic shielding to reduce electromagnetic interference by minimizing leakage magnetic fields, enhancing circuit performance. The maximum DC resistance of 14.4 mΩ ensures minimal power dissipation, and the maximum self-resonant frequency of 28 MHz guarantees stable operation within high-frequency switching environments.

Applications include high-efficiency switching regulators (>86%), integrated DC-DC converters, and graphic cards where noise reduction and power handling are critical. The surface mount termination type facilitates automated PCB assembly processes via tape and reel packaging.

The product is manufactured in China, ensuring quality through stringent manufacturing processes. This Wurth Elektronik inductor series is known for durability and reliability in industrial, automotive, and consumer electronics sectors.

Magnetically shielded design reduces leakage magnetic field. Supports high current loading with maximum DC current of 6 A. Operates reliably over a wide temperature range from -40°C to 125°C. Compact 1050 surface mount package dimensions 10 x 10 x 5 mm.

Conforms to automotive AEC-Q200 and IPC/JEDEC J-STD-020D standards. Surface mount termination style for efficient PCB integration. Low DC resistance of 14.4 milliohms minimizes power loss. Maximum self-resonant frequency of 28 MHz for stable high-frequency performance.

Ideal for use in switching regulators, DC-DC converters, and graphic cards. Explore more Surface Mount Inductors and electronic components in the EnvMart catalog for your industrial and commercial requirements.
